AF10 Case IH AF10 Specifications & Technical Data (2024—2026)

Engine power: 420kW – Model series: AF – Rotor Ø: 762mm – Grain tank size: 16000l – Weight: 25.509t – Transport height: 3.98m

Combine Harvesters Case IH AF10

Technical specs - AF10 Case IH

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Engine power
420 kW
Model series
AF
Rotor Ø
762 mm
Grain tank size
16000 l
Weight
25.509 t
Transport height
3.98 m
Engine manuf.
FPT
Engine type
Cursor 13
Emission level
V

More technical details, like: standard tyres, threshing system, walkers, steering, transmission type, transport length, transport width, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke are available in the full technical specs.

Basic model self-propelled motor incl. standard cutting is a 0 for the size specification so that means, that no information is available.

Special equipment

Cabin
Yes
Straw chopper
No
Stone Trap
No
Hillside levelling
No
Chaff spreader
No
Loss monitoring
No
Rollover protection
No
All-wheel drive
No
Aircondition
No

Download datasheets (PDF)

Case IH AF10 FAQ

When was the Case IH AF10 first produced?

The Case IH AF10 was first produced in 2024.

What is the weight of the Case IH AF10 combine harvester?

The Case IH AF10 combine harvester weighs 25.509 tonnes.

What is the transport height of the Case IH AF10 combine harvester?

The Case IH AF10 has a transport height of 3.98 meters.

What is the engine power of the Case IH AF10 combine harvester?

The Case IH AF10 combine harvester has an engine power of 570 kW.

What is the grain tank volume capacity of the Case IH AF10 combine harvester?

The Case IH AF10 combine harvester has a grain tank size of 16,000 liters.

What is the rotor diameter of the Case IH AF10 combine harvester?

The Case IH AF10 combine harvester has a rotor diameter of 762 millimeters.
