4100 Multi Basis Steyr 4100 Multi Basis Specifications & Technical Data (2016—2018)

Engine power: 73kW – Model series: Multi – Back tyres: 480/80 R 34 – Front tyres: 400/80 R 24 – Transport length: 4.4m – Transport width: 2.1m

4WD Tractors Steyr 4100 Multi Basis
4WD Tractors Steyr 4100 Multi Basis
4WD Tractors Steyr 4100 Multi Basis
4WD Tractors Steyr 4100 Multi Basis
4WD Tractors Steyr 4100 Multi Basis
4WD Tractors Steyr 4100 Multi Basis

Technical specs - 4100 Multi Basis Steyr

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Engine power
73 kW
Model series
Multi
Back tyres
480/80 R 34
Front tyres
400/80 R 24
Transport length
4.4 m
Transport width
2.1 m
Transport height
2.73 m
Travel speed
40 km/h
Transmission
32/32
Engine manuf.
CNH
Engine type
k.A.
Displacement
3.4 l
Revolutions at max torque
2200 rpm
Max. torque
430/1500 Nm
No. of cylinders
4

More technical details, like: transmission type, weight, control unit, steering, three point category, dimension lxwxh, cylinder bore x stroke, emission level are available in the full technical specs.

is a 0 for the size specification so that means, that no information is available.

Special equipment

Cabin
Yes
Front hydraulics
Yes
Front PTO
Yes
Air brakes
No
ISO Bus
No
Aircondition
No

Download datasheets (PDF)

Steyr 4100 Multi Basis FAQ

When was the Steyr 4100 Multi Basis manufactured?

The Steyr 4100 Multi Basis was manufactured from 2016 to 2018.

What are the physical dimensions of the Steyr 4100 Multi Basis tractor?

The Steyr 4100 Multi Basis tractor has a transport length of 4.4 meters, a transport width of 2.1 meters, and a transport height of 2.73 meters.

What is the engine power of the Steyr 4100 Multi Basis?

The Steyr 4100 Multi Basis has an engine power of 73 kW.

What is the travel speed of the Steyr 4100 Multi Basis?

The Steyr 4100 Multi Basis has a travel speed of 40 km/h.

What are the transmission speeds for the Steyr 4100 Multi Basis?

The Steyr 4100 Multi Basis has a transmission with 32 forward speeds and 32 reverse speeds.

What are the wheel and tyre specifications of the Steyr 4100 Multi Basis?

The Steyr 4100 Multi Basis has back tyres sized 480/80 R 34 and front tyres sized 400/80 R 24.

How much is a Steyr 4100 Multi Basis 4WD Tractor (2016u20132018) worth?

The residual value of the Steyr 4100 Multi Basis depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
