Explorer 120 HD SAME Explorer 120 HD Specifications & Technical Data (2017—2025)

The SAME Explorer 120 HD is a 4-wheel drive tractor manufactured by SAME since 2017. It has a weight of 4.22 tons and is powered b…

The SAME Explorer 120 HD is a 4-wheel drive tractor manufactured by SAME since 2017. It has a weight of 4.22 tons and is powered by an engine with a power output of 85 kW. The tractor has a transport length of 4.314 meters and can travel at a speed of 40 km/h. It has a transport width of 2.609 meters and a transport height of 2.732 meters. The tractor is equipped with a cabin and has 0 control units.

Explorer 120 HD

Years of manufacture: 2017—2025

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - Explorer 120 HD SAME

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Engine power: 85 kW

Model series: Explorer

Back tyres: 16.9 R34

Front tyres: 14.9 R24

Transport length: 4.314 m

Transport width: 2.609 m

Transport height: 2.732 m

Travel speed: 40 km/h

Transmission: 10/10

Transmission type: LS

Weight: 4.22 t

Control unit: -/1 ew/dw

Steering: h

Engine manuf.: SDF

Engine type: FARMotion

Displacement: 3.849 l

Revolutions at max torque: 2200 rpm

No. of cylinders: 4

Emission level: Tier 4 f

More technical details, like: three point category, dimension lxwxh, max. torque, cylinder bore x stroke are available in the full technical specs.

is a 0 for the size specification so that means, that no information is available.

Special equipment

Cabin: Yes
Front hydraulics: No
Front PTO: No
Air brakes: No
ISO Bus: No
Aircondition: No

Download datasheets (PDF)

SAME Explorer 120 HD FAQ

When was the SAME Explorer 120 HD manufactured?

The SAME Explorer 120 HD was first produced in 2017.

What is the weight of the SAME Explorer 120 HD?

The SAME Explorer 120 HD has a weight of 4.22 tonnes.

What are the transport dimensions of the SAME Explorer 120 HD?

The SAME Explorer 120 HD has a transport length of 4.31 meters, a transport width of 2.61 meters, and a transport height of 2.73 meters.

What is the engine power of the SAME Explorer 120 HD?

The SAME Explorer 120 HD has an engine power of 85 kW.

What is the travel speed of the SAME Explorer 120 HD?

The SAME Explorer 120 HD has a travel speed of 40 km/h.

What type of transmission does the SAME Explorer 120 HD have?

The SAME Explorer 120 HD is equipped with a Powershift transmission.

What type of steering does the SAME Explorer 120 HD have?

The SAME Explorer 120 HD is equipped with hydraulic steering.

What are the wheel and tyre specifications of the SAME Explorer 120 HD?

The SAME Explorer 120 HD has front tyres sized 14.9 R24 and back tyres sized 16.9 R34.

How much is a SAME Explorer 120 HD 4WD Tractor (2017u20132025) worth?

The residual value of the SAME Explorer 120 HD depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
