Explorer 110 HD SAME Explorer 110 HD Specifications & Technical Data (2017—2025)

The SAME Explorer 110 HD is a 4-wheel drive tractor manufactured by SAME since 2017. It has a weight of 4.22 tons and is powered b…

The SAME Explorer 110 HD is a 4-wheel drive tractor manufactured by SAME since 2017. It has a weight of 4.22 tons and is powered by an engine with a power output of 78 kW. The tractor has a transport length of 4.314 meters and can travel at a speed of 40 km/h. It has a transport width of 2.609 meters and a transport height of 2.732 meters. The tractor is equipped with 2 control units and comes with special equipment such as a cabin.

4WD Tractors SAME Explorer 110 HD
4WD Tractors SAME Explorer 110 HD
4WD Tractors SAME Explorer 110 HD
4WD Tractors SAME Explorer 110 HD

Technical specs - Explorer 110 HD SAME

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Engine power
78 kW
Model series
Explorer
Back tyres
480/70 R34
Front tyres
420/70 R24
Transport length
4.314 m
Transport width
2.609 m
Transport height
2.732 m
Travel speed
40 km/h
Transmission
20/20
Transmission type
LS
Weight
4.22 t
Control unit
2 ew/dw
Steering
h
Engine manuf.
SDF
Engine type
FARMotion
Displacement
3.849 l
Revolutions at max torque
2200 rpm
No. of cylinders
4
Emission level
Tier 4 f

More technical details, like: three point category, dimension lxwxh, max. torque, cylinder bore x stroke are available in the full technical specs.

is a 0 for the size specification so that means, that no information is available.

Special equipment

Cabin
Yes
Front hydraulics
No
Front PTO
No
Air brakes
No
ISO Bus
No
Aircondition
No

Download datasheets (PDF)

SAME Explorer 110 HD FAQ

When was the SAME Explorer 110 HD manufactured?

The SAME Explorer 110 HD was first produced in 2017.

What is the weight of the SAME Explorer 110 HD?

The SAME Explorer 110 HD has a weight of 4.22 tonnes.

What are the physical dimensions of the SAME Explorer 110 HD?

The SAME Explorer 110 HD has a transport length of 4.31 meters, a transport width of 2.61 meters, and a transport height of 2.73 meters.

What is the engine power of the SAME Explorer 110 HD?

The SAME Explorer 110 HD has an engine power of 78 kW.

What is the travel speed of the SAME Explorer 110 HD?

The SAME Explorer 110 HD has a travel speed of 40 km/h.

What are the drivetrain and transmission specifications of the SAME Explorer 110 HD?

The SAME Explorer 110 HD has a powershift transmission with 20 forward speeds and 20 reverse speeds.

What type of steering does the SAME Explorer 110 HD have for maneuverability?

The SAME Explorer 110 HD features hydraulic steering for maneuverability.

What are the wheel and tyre specifications of the SAME Explorer 110 HD?

The SAME Explorer 110 HD has front tyres sized 420/70 R24 and back tyres sized 480/70 R34.

How much is a SAME Explorer 110 HD 4WD Tractor (2017u20132025) worth?

The residual value of the SAME Explorer 110 HD depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
