Explorer 105 SAME Explorer 105 Specifications & Technical Data (2023—2026)

The SAME Explorer 105 is a 4-wheel drive tractor manufactured by SAME since 2023. It has a weight of 3.95 tons and is powered by a…

The SAME Explorer 105 is a 4-wheel drive tractor manufactured by SAME since 2023. It has a weight of 3.95 tons and is powered by an engine with a power output of 78 kW. The tractor has a transport length of 4.407 meters and can travel at a speed of 40 km/h. It has a transport width of 2.06 meters and is equipped with a cabin.

4WD Tractors SAME Explorer 105

Technical specs - Explorer 105 SAME

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Engine power
78 kW
Model series
Explorer
Back tyres
270/95 R44
Front tyres
230/95 R32
Transport length
4.407 m
Transport width
2.06 m
Travel speed
40 km/h
Transmission
10/10
Transmission type
m
Weight
3.95 t
Control unit
2 ew/dw
Steering
h
three point category
2
Engine manuf.
SDF
Engine type
FARMotion 45
Displacement
3.849 l
Revolutions at max torque
2000 rpm
Max. torque
433/1400 Nm
No. of cylinders
4
Cylinder bore x stroke
103x115,5 mm
Emission level
V

More technical details, like: transport height, dimension lxwxh are available in the full technical specs.

is a 0 for the size specification so that means, that no information is available.

Special equipment

Cabin
Yes
Front hydraulics
No
Front PTO
No
Air brakes
No
ISO Bus
No
Aircondition
No

Download datasheets (PDF)

SAME Explorer 105 FAQ

When was the SAME Explorer 105 first produced?

The SAME Explorer 105, part of the Explorer series, was first produced in 2023.

What is the weight of the SAME Explorer 105?

The SAME Explorer 105 has a weight of 3.95 tonnes.

What are the physical dimensions of the SAME Explorer 105?

The SAME Explorer 105 has a transport length of 4.41 meters and a transport width of 2.06 meters.

What is the engine power of the SAME Explorer 105?

The SAME Explorer 105 has an engine power of 78 kW.

What is the travel speed of the SAME Explorer 105?

The SAME Explorer 105 has a travel speed of 40 km/h.

What are the wheel and tyre specifications for the SAME Explorer 105?

The SAME Explorer 105 has front tyres sized 230/95 R32 and back tyres sized 270/95 R4.

What is the three-point hitch category of the SAME Explorer 105?

The SAME Explorer 105 has a category 2 three-point hitch.

How much is a SAME Explorer 105 4WD Tractor (2023u20132025) worth?

The residual value of the SAME Explorer 105 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
