Dorado 80 Classic SAME Dorado 80 Classic Specifications & Technical Data (2017—2024)

The SAME Dorado 80 Classic is a 4 wheel drive tractor manufactured since 2017. It has a weight of 3.2 tons and is equipped with a …

The SAME Dorado 80 Classic is a 4 wheel drive tractor manufactured since 2017. It has a weight of 3.2 tons and is equipped with a cabin. The tractor is powered by an engine with a power output of 55.4 kW. It has a transport length of 3.997 meters, a travel speed of 40 km/h, a transport width of 2.18 meters, and a transport height of 2.59 meters.

4WD Tractors SAME Dorado 80 Classic
4WD Tractors SAME Dorado 80 Classic
4WD Tractors SAME Dorado 80 Classic
4WD Tractors SAME Dorado 80 Classic
4WD Tractors SAME Dorado 80 Classic
4WD Tractors SAME Dorado 80 Classic

Technical specs - Dorado 80 Classic SAME

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Engine power
55.4 kW
Model series
Dorado
Back tyres
420/70 R30
Front tyres
360/70 R20
Transport length
3.997 m
Transport width
2.18 m
Transport height
2.59 m
Travel speed
40 km/h
Transmission
10/10
Transmission type
m
Weight
3.2 t
Control unit
2/- ew/dw
Steering
h
Engine manuf.
SDF
Engine type
FARMotion
Displacement
2.887 l
Revolutions at max torque
2000 rpm
No. of cylinders
3
Emission level
III B (Tier 4 i)

More technical details, like: three point category, dimension lxwxh, max. torque, cylinder bore x stroke are available in the full technical specs.

is a 0 for the size specification so that means, that no information is available.

Special equipment

Cabin
Yes
Front hydraulics
No
Front PTO
No
Air brakes
No
ISO Bus
No
Aircondition
No

Download datasheets (PDF)

SAME Dorado 80 Classic FAQ

When was the SAME Dorado 80 Classic manufactured?

The SAME Dorado 80 Classic was first produced in 2017.

What is the weight of the SAME Dorado 80 Classic?

The SAME Dorado 80 Classic has a weight of 3.2 tonnes.

What are the transport dimensions of the SAME Dorado 80 Classic?

The SAME Dorado 80 Classic has a transport length of 4 meters, a transport width of 2.18 meters, and a transport height of 2.59 meters.

What is the engine power of the SAME Dorado 80 Classic?

The SAME Dorado 80 Classic has an engine power of 55.4 kW.

What is the travel speed of the SAME Dorado 80 Classic?

The SAME Dorado 80 Classic has a travel speed of 40 km/h.

What type of transmission does the SAME Dorado 80 Classic have?

The SAME Dorado 80 Classic is equipped with a mechanical transmission.

What type of steering does the SAME Dorado 80 Classic have?

The SAME Dorado 80 Classic has hydraulic steering.

What are the wheel and tyre specifications of the SAME Dorado 80 Classic?

The SAME Dorado 80 Classic has back tyres sized 420/70 R30 and front tyres sized 360/70 R20.
