Quantum 100 N Case IH Quantum 100 N Specifications & Technical Data (2023—2026)

Engine power: 73kW – Model series: Quantum – Back tyres: 420/70 R28 – Front tyres: 280/70 R20 – Transport length: 4.18m – Transport width: 1.35m

Quantum 100 N

Years of manufacture: 2023—2026

Buy & Rent
Spare parts
Transport
News

Technical specs - Quantum 100 N Case IH

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Engine power: 73 kW

Model series: Quantum

Back tyres: 420/70 R28

Front tyres: 280/70 R20

Transport length: 4.18 m

Transport width: 1.35 m

Transport height: 2.47 m

Travel speed: 40 km/h

Transmission: 32/16

Weight: 3.1 t

Control unit: 2 ew/dw

Steering: h

Engine manuf.: FPT

Engine type: F36

Displacement: 3.6 l

Revolutions at max torque: 2300 rpm

Max. torque: 407/1300 Nm

No. of cylinders: 4

Emission level: V

is a 0 for the size specification so that means, that no information is available.

Special equipment

Cabin: Yes
Front hydraulics: No
Front PTO: No
Air brakes: No
ISO Bus: No
Aircondition: Yes

Case IH Quantum 100 N FAQ

When was the Case IH Quantum 100 N manufactured?

The Case IH Quantum 100 N began production in 2023.

What is the weight of the Case IH Quantum 100 N?

The Case IH Quantum 100 N has a weight of 3.1 tonnes.

What are the physical dimensions of the Case IH Quantum 100 N?

The Case IH Quantum 100 N has a transport length of 4.18 meters, a transport width of 1.35 meters, and a transport height of 2.47 meters.

What is the engine power of the Case IH Quantum 100 N?

The Case IH Quantum 100 N has an engine power of 73 kW.

What is the travel speed of the Case IH Quantum 100 N?

The Case IH Quantum 100 N has a travel speed of 40 km/h.

What are the transmission speeds for the Case IH Quantum 100 N?

The Case IH Quantum 100 N has a transmission with 32 forward speeds and 16 reverse speeds.

What type of steering does the Case IH Quantum 100 N have for maneuverability?

The Case IH Quantum 100 N is equipped with hydraulic steering.

What are the wheel and tyre specifications of the Case IH Quantum 100 N?

The Case IH Quantum 100 N has back tyres sized 420/70 R28 and front tyres sized 280/70 R20.

How much is a Case IH Quantum 100 N 4WD Tractor (2023u20132025) worth?

The residual value of the Case IH Quantum 100 N depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
