Case IH Magnum 340 Specifications & Technical Data (2020-2025)

The Case IH Magnum 340 is a 4-wheel drive tractor manufactured by Case IH from 2020 to 2023. It has a weight of 11.73 tons and is …

The Case IH Magnum 340 is a 4-wheel drive tractor manufactured by Case IH from 2020 to 2023. It has a weight of 11.73 tons and is powered by an engine with a power output of 276 kW. The tractor has a transport length of 6.575 meters and a travel speed of 40 km/h. It has a transport width of 2.75 meters and a transport height of 3.375 meters. The tractor is equipped with a 4-control unit (ew/dw) and comes with special equipment including air conditioning and a cabin.

Technical specs - Magnum 340 Case IH

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Engine power
276 kW
Model series
Magnum
Back tyres
710/70 R42
Front tyres
600/70 R30
Transport length
6.58 m
Transport width
2.75 m
Transport height
3.38 m
Travel speed
40 km/h
Transmission
18/4
Transmission type
m
Weight
11.73 t
Control unit
4 ew/dw
Engine manuf.
FPT
Engine type
k.A.
Displacement
8.7 l
Revolutions at max torque
2000 rpm
No. of cylinders
6
Emission level
V

is a 0 for the size specification so that means, that no information is available.

Special equipment

Cabin
Yes
Front hydraulics
No
Front PTO
No
Air brakes
No
ISO Bus
No
Aircondition
Yes

Download datasheets (PDF)

FAQ

What is the weight of Case IH Magnum 340?

The weight of Case IH Magnum 340 is 11.73 tons.

What is the size of the Case IH Magnum 340 4WD tractor?

The size of the Case IH Magnum 340 4WD tractor is 2.75 meters in width, 3.38 meters in height, and 6.58 meters in length.

What engine does the Case IH Magnum 340 4WD tractor have?

The Case IH Magnum 340 4WD tractor has an FPT engine with 375 kW power, 8.7 l displacement, 2000 rpm at max torque, and 6 cylinders.
