SA221 R Yanmar SA221 R Specifications & Technical Data (2018—2026)

The Yanmar SA221 R is a 4-wheel drive tractor manufactured by Yanmar since 2018. It has a weight of 0.768 tons and is powered by a…

The Yanmar SA221 R is a 4-wheel drive tractor manufactured by Yanmar since 2018. It has a weight of 0.768 tons and is powered by an engine with a power output of 16.1 kW. The tractor has a transport length of 2.699 meters and can travel at a speed of 13 km/h. It has a transport width of 1.2 meters and a transport height of 2.273 meters.

Vehicles Compact Utility Tractors Yanmar SA221 R
Vehicles Compact Utility Tractors Yanmar SA221 R
Vehicles Compact Utility Tractors Yanmar SA221 R
Vehicles Compact Utility Tractors Yanmar SA221 R
Vehicles Compact Utility Tractors Yanmar SA221 R
Vehicles Compact Utility Tractors Yanmar SA221 R

Technical specs - SA221 R Yanmar

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight without attachment
0.768 t
Travel speed
13 km/h
Back tyres
26x12.0-12 4PR
Front tyres
18x8.50-10 4PR
Transport length
2.699 m
Transport width
1.198 m
Transport height
1.515 m
Transmission
1
Attachment
H/M/F
Model series
SA
Engine manuf.
Yanmar
Engine type
3TNM72-DRE
Engine power
16.1 kW
Displacement
0.903 l
Revolutions at max torque
3000 rpm
Max. torque
55.7 Nm
No. of cylinders
3
Cylinder bore x stroke
72x74 mm
Emission level
V

More technical details, like: bridge length, bridge width, steering mode, dimension lxwxh, weight are available in the full technical specs.

Special equipment

Cabin
No
Front hydraulics
No
Front PTO
No
All-wheel drive
Yes
Codriver seat
No
Rear hydraulic
No
Frontblade
No
Load tippable
No
Rear PTO
No

Download datasheets (PDF)

Yanmar SA221 R FAQ

What is the weight of Yanmar SA221 R?

The weight of Yanmar SA221 R is 0.77 tons.

What is the size of the Yanmar SA221 R 4WD tractor?

The size of the Yanmar SA221 R 4WD tractor is 1.2 meters in width, 2.27 meters in height, and 2.7 meters in length.

What engine does the Yanmar SA221 R 4WD tractor have?

The Yanmar SA221 R 4WD tractor is equipped with a Yanmar 3TNM72-DRE engine, which has a power output of 22 kW, a displacement of 0.9 liters, a maximum torque of 55.7 Nm at 3000 rpm, and features 3 cylinders.

How much is Yanmar SA221 R (2018 - 2024) worth?

The residual value of Yanmar SA221 R depends on machine's individual parameters. Visit LECTURA Valuation to check it.
