TLE 3410 AHL Iseki TLE 3410 AHL Specifications & Technical Data (2023—2026)

Weight without attachment: 1.41t – Travel speed: 27km/h – Back tyres: 11.2-24 – Front tyres: 240/70 R16 – Transport length: 3.07m – Transport width: 1.43m

Vehicles Compact Utility Tractors Iseki TLE 3410 AHL

Technical specs - TLE 3410 AHL Iseki

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight without attachment
1.41 t
Travel speed
27 km/h
Back tyres
11.2-24
Front tyres
240/70 R16
Transport length
3.07 m
Transport width
1.43 m
Transport height
2.62 m
Transmission
stfl.
Attachment
H/F
Model series
TLE
Engine manuf.
Iseki
Engine type
E3FH
Engine power
29.4 kW
Displacement
1.498 l
Revolutions at max torque
2600 rpm
Max. torque
112/1600 Nm
No. of cylinders
3
Emission level
V

More technical details, like: bridge length, bridge width, steering mode, dimension lxwxh, cylinder bore x stroke, weight are available in the full technical specs.

Special equipment

Cabin
No
Front hydraulics
Yes
Front PTO
No
All-wheel drive
Yes
Codriver seat
No
Rear hydraulic
Yes
Frontblade
No
Load tippable
No
Rear PTO
Yes
