MF 9205 Massey Ferguson Telehandler Specs & Dimensions (2012 - 2015)

Name: Massey Ferguson MF 9205 Telehandlers
Brand: Massey Ferguson

The Massey Ferguson MF 9205 is a telehandler manufactured from 2012 to 2015. It has a weight of 4.69 tons and a transport length o…

The Massey Ferguson MF 9205 is a telehandler manufactured from 2012 to 2015. It has a weight of 4.69 tons and a transport length of 4 meters. The nominal load at the center of gravity is 2.2 tons, and it has a lifting height of 5.2 meters. The capacity at full forward reach is 1 ton. The center of gravity is located at 500 millimeters. The transport width is 1.84 meters, and the transport height is 1.985 meters. It is equipped with StVZO equipment.

MF 9205

Years of manufacture: 2012—2015

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

See offers

Technical specs - MF 9205 Massey Ferguson

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Nominal load at COG: 2.2 t

Model series: 9000

Centre of gravity: 500 mm

Standard tyres: 325/70-18

Transmission type: Hy

Max. Reach horizontal: 3 m

Capacity at full forward reach: 1 t

Lifting height: 5.2 m

Weight: 4.69 t

Transport length: 4 m

Transport width: 1.84 m

Transport height: 1.985 m

Travel speed: 25 km/h

max. climbing ability: 30 %

Engine manuf.: Kubota

Engine type: V3800DI-T

Engine power: 56 kW

More technical details, like: capacity at full lift height, drive system, voltage, traction motor, hoist motor, travel speed with / without load, hoisting with / without load, lowering with load, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, emission level, cab position, chassis type, levelling - chassis, stabilisers, drive - 2w / 4w, transmission type, engine manufacturer, engine model, emission rating, aspiration, rated speed, engine output - net, torque, tyre - front size, service brake - type, service brake - location, length - front of carriage, height - over cab, width - operating, wheelbase, lift height - maximum, reach - maximum, reach - at maximum lift height, unstabilised lift height - with maximum capacity, turning radius - over tyres, lift capacity - maximum, lift capacity - to max height, lift capacity - to max reach, unstabilised lift capacity - maximum, unstabilised lift capacity - to max height, unstabilised lift capacity - to max reach, fuel tank, number of boom sections, load centre, lift capacity - fork maximum, speed - forward maximum, operating weight are available in the full technical specs.

All specifications and prices refer to basic models with standard fork carrier, 2 standard prongs, without additional hydraulic and shovel

Special equipment

Diesel particulate filter: No
StVZO Equipment: Yes
Inclination correction: No
Side displacement: No
