    Case TX130-45 telehandler specs (2008 - 2016)

    Rate this machine now!

    The TX 130-45 telehandler model is manufactured by case. Find and download detailed specs and data sheets for this machine here. ... Read more

    The TX 130-45 telehandler model is manufactured by case. Find and download detailed specs and data sheets for this machine here.

    Equipped with a powerful CNH engine, this TX 130-45 10.63t machine can provide 88kW or 118 horse power for the telehandler. This case telehandler belongs to the biggest machine segment in the telehandlers category. The TX 130-45’s size is 2.445m x 5.85m x 2.45m. The size of standard tyres for this case TX 130-45 is 400/70x20. The Telehandler TX 130-45 case is designed to travel at a top speed of 35km/h. It can operate with up to 8.65m of horizontal reach. It can lift 4.5t of nominal load with a 500mm centre of gravity. The TX 130-45 has a lift height of 12.45m, to which it can lift 4t. At full forward reach, this model can control a weight of 1.8t.

    Diesel particulate filter, StVZO Equipment and Side displacement are not provided on this model as of 2016. Find detailed specifications and machine details in the original case TX 130-45 datasheet. Available in Italian, English, Chinese, German, French and Spanish, LECTURA Specs offers a free download of highly detailed specifications and machine descriptions of this model.

    The production stopped in 2016, where this TX 130-45 was available at a new list price between €95,000 and €121,000. For more detailed information about pricing and current residual values, check out the LECTURA Valuation system.

    Based on other telehandlers specifications and pricing variations, the case TX 130-45 can be considered similar to the Merlo TF 42.7 TT-CS-156, Merlo TF 45.11 T-120 and Dieci Agri Max 45.8. At present, other telehandlers, which range from up to are produced by case. Of these, are the most frequently visited on LECTURA Specs. Want more detailed specifications? Download the latest case TX 130-45 specs data sheet on LECTURA Specs today!

    Technical specs - TX130-45 Case

    Specification

    Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur.Contact our team with any change suggestion.

    • Nominal load at COG 4.5 t
    • Standard tyres 400/70x20
    • Centre of gravity 500 mm
    • Max. Reach horizontal 8.65 m
    • Capacity at full forward reach 1.8 t
    • Lifting height 12.45 m
    • Capacity at full lift height 4 t
    • Weight 10.63 t
    • Transport length 5.85 m
    • Transport width 2.445 m
    • Transport height 2.45 m
    • Travel speed 35 km/h
    • Engine manuf. CNH
    • Engine type F4GE 9484J*60
    • Engine power 88 kW
    • Transmission type ###
    • max. climbing ability ###
    • Dimension lxwxh ###
    • Displacement ###
    • Revolutions at max torque ###
    • Max. torque ###
    • No. of cylinders ###
    • Cylinder bore x stroke ###
    • Emission level ###
    • Cab Position ###
    • Chassis Type ###
    • Levelling - Chassis ###
    • Stabilisers ###
    • Drive - 2W / 4W ###
    • Transmission Type ###
    • Telematics Available ###
    • Engine Manufacturer ###
    • Engine Model ###
    • Emission Rating ###
    • Aspiration ###
    • Rated Speed ###
    • Engine Output - Net ###
    • Torque ###
    • Tyre - Front Size ###
    • Tyre 2 - Front Size Option ###
    • Tyre 3 - Front Size Option ###
    • Service Brake - Type ###
    • Service Brake - Location ###
    • Dimension Configuration ###
    • Length - Front Of Carriage ###
    • Height - Over Cab ###
    • Width - Operating ###
    • Wheelbase ###
    • Ground Clearance ###
    • Width - Cab ###
    • Boom Angle - Maximum ###
    • Lift Height - Maximum ###
    • Reach - Maximum ###
    • Reach - At Maximum Lift Height ###
    • Reach - Ground With Maximum Capacity ###
    • Stabilised Lift Height - With Maximum Capacity ###
    • Turning Radius - Over Tyres ###
    • Breakout Force ###
    • Lift Capacity - Maximum ###
    • Lift Capacity - To Max Height ###
    • Lift Capacity - To Max Reach ###
    • Stabilised Lift Capacity - Maximum ###
    • Stabilised Lift Capacity - To Max Height ###
    • Stabilised Lift Capacity - To Max Reach ###
    • Fuel Tank ###
    • Number Of Boom Sections ###
    • Load Centre ###
    • Lift Capacity - Fork Maximum ###
    • Speed - Forward Maximum ###
    • Operating Weight ###

    All specifications and prices refer to basic models with standard fork carrier, 2 standard prongs, without additional hydraulic and shovel

    Special equipment

    • Diesel particulate filter
    • StVZO Equipment
    • Inclination correction
    • Side displacement
