TL358 Bobcat Telehandler Specs & Dimensions (2015 - 2017)

Name: Bobcat TL358 Telehandlers
Brand: Bobcat
Rating: 10,00 (1 reviews)

Model rating: 10,00 / 10

The Bobcat TL358 is a telehandler manufactured by Bobcat from 2015 to 2017. It has a weight of 4.9 tons and a transport length of …

The Bobcat TL358 is a telehandler manufactured by Bobcat from 2015 to 2017. It has a weight of 4.9 tons and a transport length of 4.507 meters. The maximum horizontal reach is 3.103 meters, and it can lift a nominal load of 2.6 tons at the center of gravity. The lifting height is 5.8 meters, and the center of gravity is located at 500 millimeters. It has a travel speed of 31 km/h and a transport width of 2.1 meters. The transport height is 2.25 meters.

Visit Bobcat live at

TL358

Years of manufacture: 2015—2017

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
Events
News

Technical specs - TL358 Bobcat

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Nominal load at COG: 2.6 t

Model series: R

Centre of gravity: 500 mm

Standard tyres: 405/70-20

Transmission type: HY

Max. Reach horizontal: 3.103 m

Lifting height: 5.8 m

Weight: 4.9 t

Transport length: 4.507 m

Transport width: 2.1 m

Transport height: 2.25 m

Travel speed: 31 km/h

Engine manuf.: Perkins

Engine type: 1104D-44TA

Engine power: 74 kW

More technical details, like: capacity at full forward reach, capacity at full lift height, max. climbing ability, drive system, voltage, traction motor, hoist motor, travel speed with / without load, hoisting with / without load, lowering with load, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, emission level, cab position, chassis type, levelling - chassis, stabilisers, drive - 2w / 4w, transmission type, attachment quickhitch, telematics available, engine manufacturer, engine model, emission rating, aspiration, rated speed, engine output - gross, torque, tyre - front size, tyre - rear size, service brake - type, service brake - location, length - at ground, length - front of carriage, height - over cab, width - operating, wheelbase, ground clearance, width - cab, lift height - maximum, reach - maximum, reach - at maximum lift height, reach - ground with maximum capacity, unstabilised lift height - with maximum capacity, turning radius - over tyres, breakout force, lift capacity - maximum, lift capacity - to max height, lift capacity - to max reach, unstabilised lift capacity - maximum, unstabilised lift capacity - to max height, unstabilised lift capacity - to max reach, fuel tank, number of boom sections, load centre, lift capacity - fork maximum, raise time - boom, extend time - boom, speed - forward maximum, speed - reverse maximum, operating weight are available in the full technical specs.

All specifications and prices refer to basic models with standard fork carrier, 2 standard prongs, without additional hydraulic and shovel

Special equipment

Diesel particulate filter: No
StVZO Equipment: No
Inclination correction: No
Side displacement: No

Download datasheets (PDF)

Bobcat TL358 overview

Bobcat TL358 features overview

In a Compact Format

A compact format means a narrow frame (2.10 m) and an overall height adapted to your needs. Four versions are available, according to the cab position and the tyre size.

Drive

3 steering modes with semi-automatic wheels realignment

1 Two-wheel steering mode for road and high speed use.2 Four-wheel steering mode for minimum turning circles.3 Crab-steer mode for efficient filling and grading and working alongside walls and in confined spaces.

User-friendly electronic dashboard

Engine or job hours, vehicle or engine speed, boom angle, speed management, auxiliary hydraulic flow setting, permanent flow, and more... At the touch of a button, you have a clear, easy-to-read overview of all operating parameters.

Performance

Top priorities: operator safety and comfort

The Bobcat TL’s simple controls are designed around the operator to provide the most relaxed, comfortable and confident working conditions. Their practical, ergonomic layout puts the latest innovations for comfort and control at your fingertips.

Multifunction joystick

To provide maximum control of the driving direction, the forward/reverse control function is on the joystick. The operator can move forward and backward quickly and easily while keeping a grip on both the steering wheel and the joystick. So, optimum reactivity is combined with full, confident control of all machine functions. Enhanced productivity and flexibility – forward/reverse movements are combined with driving and positioning the machine. Greater safety – the operator always keeps one hand on the steering wheel.

Equipment

Panoramic Vision

By ensuring that operators are always fully aware of their surroundings, our panoramic cab design promotes much smoother working processes, higher productivity and greater safety.

Easy Maintenance

Easy access to the key maintenance components reduces the time you need for routine maintenance. This makes a big difference: minimized downtime means more productivity.
