Technical specs - H230XD-ECD9 Hyster

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Nominal load at COG
10.387 t
Centre of gravity
1220 mm
Standard tyres
14.00-R24/14.00-R24
Weight
44.198 t
Total width
4.335 m
Construction height
12.095 m
Lifting height
21.522 m
Travel speed with / without load
20/25 km/h
Hoisting with / without load
0.46/0.62 m/s
Lowering with load
0.55 m/s
max. climbing ability
36 %
Model series
H
Engine manuf.
Cummins
Engine type
QSB6.7
Engine power
172 kW
Displacement
6.7 l
Revolutions at max torque
1500 rpm
Max. torque
1044 Nm
No. of cylinders
6
Emission level
Tier 4F / Stage IV

More technical details, like: transmission type, dimension lxwxh, cylinder bore x stroke are available in the full technical specs.

L = pneumatic tyres, x = drive, SE = superelastic, P = PUR (Elastollan, Vulkollan), V = solid rubber, ND = low pressure tyres, 3 = three-wheel, 4 = four-wheel, 6 = six-wheel All specifications and prices refer to basic models with standard fork carrier, 2 standard prongs, without additional hydraulics with Simplex mast (3,3m up to 10t • 5m > 10t load capacity)

Special equipment

StVZO Equipment
No
