H210XD-ECD8 Hyster Rough Terrain Forklift Specs & Dimensions (2022 - 2026)

Nominal load at COG: 9.525t – Centre of gravity: 1220mm – Standard tyres: 14.00-R24/14.00-R24 – Weight: 41.886t – Total width: 4.1…

Nominal load at COG: 9.525t – Centre of gravity: 1220mm – Standard tyres: 14.00-R24/14.00-R24 – Weight: 41.886t – Total width: 4.11m – Construction height: 10.795m

Rough terrain forklift H210XD-ECD8 manufactured by Hyster, production years (2022 - 2026). Explore detailed H210XD-ECD8 all terrain forklift: technical details, table charts and data sheets to download. Check also the other models produced by Hyster.

Rough Terrain Forklifts Hyster H210XD-ECD8
Rough Terrain Forklifts Hyster H210XD-ECD8
Rough Terrain Forklifts Hyster H210XD-ECD8
Rough Terrain Forklifts Hyster H210XD-ECD8
Rough Terrain Forklifts Hyster H210XD-ECD8
Rough Terrain Forklifts Hyster H210XD-ECD8

Technical specs - H210XD-ECD8 Hyster

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Nominal load at COG
9.525 t
Centre of gravity
1220 mm
Standard tyres
14.00-R24/14.00-R24
Weight
41.886 t
Total width
4.11 m
Construction height
10.795 m
Lifting height
18.922 m
Travel speed with / without load
20/25 km/h
Hoisting with / without load
0.46/0.62 m/s
Lowering with load
0.55 m/s
max. climbing ability
37 %
Model series
H
Engine manuf.
Cummins
Engine type
QSB6.7
Engine power
172 kW
Displacement
6.7 l
Revolutions at max torque
1500 rpm
Max. torque
1044 Nm
No. of cylinders
6
Emission level
Tier 4F / Stage IV

More technical details, like: transmission type, dimension lxwxh, cylinder bore x stroke are available in the full technical specs.

L = pneumatic tyres, x = drive, SE = superelastic, P = PUR (Elastollan, Vulkollan), V = solid rubber, ND = low pressure tyres, 3 = three-wheel, 4 = four-wheel, 6 = six-wheel All specifications and prices refer to basic models with standard fork carrier, 2 standard prongs, without additional hydraulics with Simplex mast (3,3m up to 10t • 5m > 10t load capacity)

Special equipment

StVZO Equipment
No

Download datasheets (PDF)

Hyster H210XD-ECD8 overview

Drive

Hydraulic system

Hyster on-demand load-sensing hydraulic system pumps oil only when required, and can pump at lower engine rpm. This system saves fuel, reduces heat, extends component and oil life, and provides quieter operation.


Handling

Container attachment

Single-handling models are equipped with Hyster® model 586TB spreader featuring vertical twistlocks, removable blocks for handling wider domestic containers, 24" (600mm) of sideshift in each direction and +/- 8" (+/- 205mm) of mechanical pile slope. Double-handling models are equipped with Hyster® model 584LD spreader featuring horizontal hooks and side clamps, 24" (600mm) of sideshift in each direction, and +/- 6° of powered pile slope.


Cabinc & Equipment

Operator area

Ergonomically designed hydraulic controls and direction control lever are within easy reach. 7” full color, touchscreen Integrated Performance Display tracks all truck activity and is integrated with Hyster Tracker telemetry system. Telescopic, easily adjustable steer column with foot pedal. Several mechanical and air suspension seat options are available.
