S30C L Clark LPG Forklift Specs & Dimensions (2018 - 2026)

Name: Clark S30C L LPG Forklifts
Brand: Clark

Nominal load at COG: 3t – Centre of gravity: 500mm – Standard tyres: 2x/2 – Transmission type: HY – Weight: 4.219t – Total width: …

Nominal load at COG: 3t – Centre of gravity: 500mm – Standard tyres: 2x/2 – Transmission type: HY – Weight: 4.219t – Total width: 1114mm

Clark is the manufacturer of the S30C L LPG forklift. The production years for this model are (2018 - 2026). Find here detailed specs for S30C L LPG powered lift truck - in a form of table chart below and downloadable datasheet. Explore also the other forklift models produced by Clark.

S30C L

Years of manufacture: 2018—2026

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - S30C L Clark

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Nominal load at COG: 3 t

Centre of gravity: 500 mm

Standard tyres: 2x/2

Transmission type: HY

Weight: 4.219 t

Total width: 1114 mm

Construction height: 2115 mm

Turning radius: 2.109 m

Lifting height: 3.3 m

Travel speed with / without load: 17.9/18.4 km/h

Hoisting with / without load: 0.52/0.54 m/s

Lowering with load: 0.55 m/s

max. climbing ability: 29 %

Model series: S

Engine manuf.: Ford

Engine type: 2.5L

Engine power: 52 kW

More technical details, like: dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

L = pneumatic tyres, x = drive, SE = superelastic, P = PUR (Elastollan, Vulkollan), V = solid rubber, ND = low pressure tyres, 3 = three-wheel, 4 = four-wheel, 6 = six-wheel All specifications and prices refer to basic models with standard fork carrier, 2 standard prongs, without additional hydraulics with Simplex mast (3,3m up to 10t • 5m > 10t load capacity)
