GDP160EF12 Yale diesel forklift specs & dimensions (2022 - 2026)
Visit Yale live at
Technical specs - GDP160EF12 Yale
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Nominal load at COG
- 16.4 t
- Centre of gravity
- 1200 mm
- Standard tyres
- 4x/2
- Weight
- 22.681 t
- Total width
- 2541 mm
- Construction height
- 3110 mm
- Turning radius
- 5.185 m
- Lifting height
- 4.49 m
- Travel speed with / without load
- 27,1/29 km/h
- Hoisting with / without load
- 0,33/0,44 m/s
- Lowering with load
- 0,54/0,48 m/s
- max. climbing ability
- 36 %
- Model series
- GDP
- Engine manuf.
- Cummins
- Engine type
- QSB6.7
- Engine power
- 116 kW
- Displacement
- 6.7 l
- Revolutions at max torque
- 2300 rpm
- No. of cylinders
- 6
- Emission level
- III A
More technical details, like: transmission type, dimension lxwxh, max. torque, cylinder bore x stroke are available in the full technical specs.
L = pneumatic tyres, x = drive, SE = superelastic, P = PUR (Elastollan, Vulkollan), V = solid rubber, ND = low pressure tyres, 3 = three-wheel, 4 = four-wheel, 6 = six-wheel All specifications and prices refer to basic models with standard fork carrier, 2 standard prongs, without additional hydraulics with Simplex mast (3,3m up to 10t • 5m > 10t load capacity)
