Caterpillar

Caterpillar DP30N diesel forklift specs (2019 - 2024)

The Caterpillar DP30N is a diesel forklift manufactured since 2019. It has a weight of 4.35 tons and a nominal load capacity of 3 …

The Caterpillar DP30N is a diesel forklift manufactured since 2019. It has a weight of 4.35 tons and a nominal load capacity of 3 tons at the center of gravity. The forklift can lift loads up to a height of 3 meters and has a center of gravity at 500mm. It has a maximum climbing ability of 45 percent and a lowering speed of 0.53 meters per second with a load. The total width of the forklift is 1690mm and it has a turning radius of 2.38 meters. The construction height of the forklift is 2015mm.

Diesel Forklifts Caterpillar DP30N

Technical specs - DP30N Caterpillar

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Nominal load at COG
3 t
Centre of gravity
500 mm
Standard tyres
Front:  28x9-15-12 / Rear:  6.50-10-10
Weight
4.35 t
Total width
1690 mm
Construction height
2015 mm
Turning radius
2.38 m
Lifting height
3 m
Travel speed with / without load
19/19.5 km/h
Hoisting with / without load
0.51/0.54 m/s
Lowering with load
0.53 m/s
max. climbing ability
45 %
Model series
DP
Engine manuf.
N/A
Engine type
S4S
Engine power
35.3 kW
Revolutions at max torque
2250 rpm
No. of cylinders
4

More technical details, like: transmission type, dimension lxwxh, displacement, max. torque, cylinder bore x stroke, emission level are available in the full technical specs.

L = pneumatic tyres, x = drive, SE = superelastic, P = PUR (Elastollan, Vulkollan), V = solid rubber, ND = low pressure tyres, 3 = three-wheel, 4 = four-wheel, 6 = six-wheel All specifications and prices refer to basic models with standard fork carrier, 2 standard prongs, without additional hydraulics with Simplex mast (3,3m up to 10t • 5m > 10t load capacity)
