Technical specs - GDP100DF Yale
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Nominal load at COG
- 10.5 t
- Centre of gravity
- 600 mm
- Standard tyres
- L 4x/2
- Weight
- 14.883 t
- Total width
- 2490 mm
- Construction height
- 3082 mm
- Turning radius
- 4.107 m
- Lifting height
- 4.925 m
- Travel speed with / without load
- 29,5/30,8 km/h
- Hoisting with / without load
- 0,39/0,4 m/s
- Lowering with load
- 0,54/0,48 m/s
- max. climbing ability
- 47 %
- Model series
- GDP
- Engine manuf.
- Mercedes-Benz
- Engine type
- OM934
- Engine power
- 129 kW
- Displacement
- 5.1 l
- Revolutions at max torque
- 2200 rpm
- No. of cylinders
- 4
- Emission level
- V
More technical details, like: transmission type, dimension lxwxh, max. torque, cylinder bore x stroke are available in the full technical specs.
L = pneumatic tyres, x = drive, SE = superelastic, P = PUR (Elastollan, Vulkollan), V = solid rubber, ND = low pressure tyres, 3 = three-wheel, 4 = four-wheel, 6 = six-wheel All specifications and prices refer to basic models with standard fork carrier, 2 standard prongs, without additional hydraulics with Simplex mast (3,3m up to 10t • 5m > 10t load capacity)
