C 100 H Raniero diesel forklift specs & dimensions (2004 - 2010)

Name: Raniero C 100 H Diesel Forklifts
Brand: Raniero

The Raniero C 100 H is a diesel forklift manufactured by Raniero from 2004 to 2010. It has a weight of 15.38 tons and a nominal lo…

The Raniero C 100 H is a diesel forklift manufactured by Raniero from 2004 to 2010. It has a weight of 15.38 tons and a nominal load at the center of gravity of 10 tons. The lifting height of this forklift is 3.2 meters, with a center of gravity at 600 millimeters. It has a maximum climbing ability of 28 percent and a total width of 2270 millimeters. The turning radius is 2.95 meters, and the construction height is 2760 millimeters.

C 100 H

Years of manufacture: 2004—2010

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

See offers

Technical specs - C 100 H Raniero

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Nominal load at COG: 10 t

Centre of gravity: 600 mm

Standard tyres: SE4/2

Transmission type: HY

Weight: 15.38 t

Total width: 2270 mm

Construction height: 2760 mm

Turning radius: 2.95 m

Lifting height: 3.2 m

Travel speed with / without load: 18/20 km/h

Hoisting with / without load: 0.43/0.48 m/s

Lowering with load: 0.45 m/s

max. climbing ability: 28 %

Model series: C

Engine manuf.: Deutz

Engine type: TCD3.6

Engine power: 90 kW

More technical details, like: dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

L = pneumatic tyres, x = drive, SE = superelastic, P = PUR (Elastollan, Vulkollan), V = solid rubber, ND = low pressure tyres, 3 = three-wheel, 4 = four-wheel, 6 = six-wheel All specifications and prices refer to basic models with standard fork carrier, 2 standard prongs, without additional hydraulics with Simplex mast (3,3m up to 10t • 5m > 10t load capacity)

Download datasheets (PDF)

C 100 H Raniero Specification for Europe (EN, IT)
