FD 50 T-M1GG3 Maximal diesel forklift specs & dimensions (2010 - 2016)

Name: Maximal FD 50 T-M1GG3 Diesel Forklifts
Brand: Maximal

The Maximal FD 50 T-M1GG3 is a diesel forklift manufactured by Maximal from 2010 to 2016. It has a weight of 7.1 tons and a nomina…

The Maximal FD 50 T-M1GG3 is a diesel forklift manufactured by Maximal from 2010 to 2016. It has a weight of 7.1 tons and a nominal load capacity of 5 tons at the center of gravity. The forklift can lift loads up to a height of 3 meters, with a center of gravity at 500mm. It has a maximum climbing ability of 17 percent and a total width of 1480mm. The travel speed with and without load is 18 km/h. The forklift has a turning radius of 2.81 meters and a construction height of 2265mm.

Maximal FD 50 T-M1GG3 Dimensions and Size

FD 50 T-M1GG3

Years of manufacture: 2010—2016

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - FD 50 T-M1GG3 Maximal

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Nominal load at COG: 5 t

Centre of gravity: 500 mm

Standard tyres: VR 300-15-18PR HR 7.00-12-12PR

Weight: 7.1 t

Total width: 1480 mm

Construction height: 2265 mm

Turning radius: 2.81 m

Lifting height: 3 m

Travel speed with / without load: 18 km/h

Hoisting with / without load: 0.45 m/s

Lowering with load: 0.5 m/s

max. climbing ability: 17 %

Model series: M

Engine manuf.: Yituo

Engine type: 4.108

Engine power: 57 kW

More technical details, like: transmission type, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

L = pneumatic tyres, x = drive, SE = superelastic, P = PUR (Elastollan, Vulkollan), V = solid rubber, ND = low pressure tyres, 3 = three-wheel, 4 = four-wheel, 6 = six-wheel All specifications and prices refer to basic models with standard fork carrier, 2 standard prongs, without additional hydraulics with Simplex mast (3,3m up to 10t • 5m > 10t load capacity)

Download datasheets (PDF)

FD 50 T-M1GG3 Maximal Specification for Europe (EN)
