FD 40 T-M2WE3 Maximal diesel forklift specs & dimensions (2010 - 2016)

Name: Maximal FD 40 T-M2WE3 Diesel Forklifts
Brand: Maximal

The Maximal FD 40 T-M2WE3 is a diesel forklift manufactured by Maximal from 2010 to 2016. It has a weight of 5.1 tons and a nomina…

The Maximal FD 40 T-M2WE3 is a diesel forklift manufactured by Maximal from 2010 to 2016. It has a weight of 5.1 tons and a nominal load at the center of gravity of 4 tons. The forklift can lift loads up to a height of 3 meters, with a center of gravity at 500mm. It has a maximum climbing ability of 18 percent and a total width of 1410mm. The travel speed with or without a load is 18 km/h. The forklift has a turning radius of 2.6 meters and a construction height of 2260mm.

Maximal FD 40 T-M2WE3 Dimensions and Size

FD 40 T-M2WE3

Years of manufacture: 2010—2016

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - FD 40 T-M2WE3 Maximal

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Nominal load at COG: 4 t

Centre of gravity: 500 mm

Weight: 5.1 t

Total width: 1410 mm

Construction height: 2260 mm

Turning radius: 2.6 m

Lifting height: 3 m

Travel speed with / without load: 18 km/h

Hoisting with / without load: 0.36 m/s

Lowering with load: 0.425 m/s

max. climbing ability: 18 %

Model series: M

Engine manuf.: Yanmar

Engine type: 4TNE98

Engine power: 42.1 kW

Emission level: EU III

More technical details, like: standard tyres, transmission type, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke are available in the full technical specs.

L = pneumatic tyres, x = drive, SE = superelastic, P = PUR (Elastollan, Vulkollan), V = solid rubber, ND = low pressure tyres, 3 = three-wheel, 4 = four-wheel, 6 = six-wheel All specifications and prices refer to basic models with standard fork carrier, 2 standard prongs, without additional hydraulics with Simplex mast (3,3m up to 10t • 5m > 10t load capacity)
