5/6 ECC 90 Konecranes diesel forklift specs & dimensions (2019 - 2026)

The Konecranes SMV 5/6 ECC 90 is a diesel forklift manufactured since 2019. It has a weight of 34.1 tons and a nominal load at the…

The Konecranes SMV 5/6 ECC 90 is a diesel forklift manufactured since 2019. It has a weight of 34.1 tons and a nominal load at the center of gravity of 9 tons. The lifting height reaches up to 16 meters, with a center of gravity at 1220 mm. It has a maximum climbing ability of 38 percent and a lowering speed with load of 0.6 m/s. The forklift can travel at a speed of 25 km/h with or without load and has a turning radius of 6 meters. The construction height is 3900 mm.

Diesel Forklifts Konecranes 5/6 ECC 90

Technical specs - 5/6 ECC 90 Konecranes

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Nominal load at COG
9 t
Centre of gravity
1220 mm
Standard tyres
4x2
Transmission type
W
Weight
36.4 t
Total width
6106 mm
Construction height
9235 mm
Turning radius
6 m
Lifting height
16.3 m
Travel speed with / without load
25 km/h
Hoisting with / without load
0,61/0,63 m/s
Lowering with load
0.6 m/s
max. climbing ability
39 %
Model series
ECC
Engine manuf.
Volvo
Engine type
TAD881-VE
Engine power
185 kW
Dimension lxwxh
1206x876x1030 mm
Displacement
7.7 l
Revolutions at max torque
2210 rpm
Max. torque
1150 Nm
No. of cylinders
6
Cylinder bore x stroke
110x135 mm
Emission level
V

L = pneumatic tyres, x = drive, SE = superelastic, P = PUR (Elastollan, Vulkollan), V = solid rubber, ND = low pressure tyres, 3 = three-wheel, 4 = four-wheel, 6 = six-wheel All specifications and prices refer to basic models with standard fork carrier, 2 standard prongs, without additional hydraulics with Simplex mast (3,3m up to 10t • 5m > 10t load capacity)
