Kalmar DCG 160-12 diesel forklift specs (2012 - 2018)

Rate this machine now!

The Kalmar DCG 160-12 is a diesel forklift manufactured from 2012 to 2018. It has a weight of 22.4 tons and a nominal load at the ... Read more

The Kalmar DCG 160-12 is a diesel forklift manufactured from 2012 to 2018. It has a weight of 22.4 tons and a nominal load at the center of gravity of 16 tons. The lifting height reaches up to 5 meters, with a center of gravity at 1200 mm. It has a maximum climbing ability of 74 percent. The lowering speed with load is 0.4 m/s. The total width of the forklift is 2540 mm, and it has a turning radius of 5.175 meters. The construction height is 2920 mm.

Technical specs - DCG 160-12 Kalmar

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur.Contact our team with any change suggestion.

  • Nominal load at COG 16 t
  • Centre of gravity 1200 mm
  • Standard tyres 4x/2
  • Transmission type W
  • Weight 22.4 t
  • Total width 2540 mm
  • Construction height 2920 mm
  • Turning radius 5.175 m
  • Lifting height 5 m
  • Travel speed with / without load 27/29 km/h
  • Hoisting with / without load 0.35/0.4 m/s
  • Lowering with load 0.4 m/s
  • max. climbing ability 74 %
  • Model series DCG
  • Engine manuf. Volvo
  • Engine type TAD761VE
  • Engine power 160 kW

More technical details, like: dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

L = pneumatic tyres, x = drive, SE = superelastic, P = PUR (Elastollan, Vulkollan), V = solid rubber, ND = low pressure tyres, 3 = three-wheel, 4 = four-wheel, 6 = six-wheel All specifications and prices refer to basic models with standard fork carrier, 2 standard prongs, without additional hydraulics with Simplex mast (3,3m up to 10t • 5m > 10t load capacity)
