35DA-9E Hyundai diesel forklift specs & dimensions (2019 - 2023)

The Hyundai 35DA-9E is a diesel forklift manufactured since 2019. It has a weight of 4.698 tons and a nominal load at the center o…

The Hyundai 35DA-9E is a diesel forklift manufactured since 2019. It has a weight of 4.698 tons and a nominal load at the center of gravity of 3.5 tons. The lifting height reaches up to 3.305 meters, with a center of gravity at 500 mm. It has a maximum climbing ability of 27.1 percent. The hoisting speed, both with and without load, is 0.45 m/s, while the lowering speed with load is 0.5 m/s. The total width of the forklift is 1228 mm, and it can travel at a speed of 19.9 km/h with or without load. The turning radius is 2.49 meters, and the construction height is 2260 mm.

Hyundai 35DA-9E Dimensions and Size

Visit Hyundai live at

Technical specs - 35DA-9E Hyundai

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Nominal load at COG
3.5 t
Centre of gravity
500 mm
Standard tyres
P 2x/2
Weight
4.698 t
Total width
1228 mm
Construction height
2260 mm
Turning radius
2.49 m
Lifting height
3.305 m
Travel speed with / without load
19.9 km/h
Hoisting with / without load
0.45/0.53 m/s
Lowering with load
0.5/0.45 m/s
max. climbing ability
27.1 %
Model series
9
Engine manuf.
Kubota
Engine type
V3307
Engine power
50 kW

More technical details, like: transmission type, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

L = pneumatic tyres, x = drive, SE = superelastic, P = PUR (Elastollan, Vulkollan), V = solid rubber, ND = low pressure tyres, 3 = three-wheel, 4 = four-wheel, 6 = six-wheel All specifications and prices refer to basic models with standard fork carrier, 2 standard prongs, without additional hydraulics with Simplex mast (3,3m up to 10t • 5m > 10t load capacity)

Download datasheets (PDF)

Hyundai 35DA-9E overview

Hyundai 35DA-9E features overview

Engine start limit

To avoid use of the truck by non qualified drivers and to protect the truck from theft, a personal activation/entrance code is delivered.


Drive

High Power Engine - KUBOTA V3307

Due to the advanced engine systems on the Kubota V3307, ultra low emissions (Stage IIIB) are achieved without the use of a particle filter. Because only a DOC (Diesel oxidation catalyst) is used, no downtime is created by the after treatment device. The Kubota engine avoids particle filter regeneration and avoids any down-time.


High Power Engine - YANMAR 4TNE92

Market approved quality of YANMAR 4TNE92 engine ensures incomparable performance, durability and excellent fuel efficiency. This engine meets EU stage III A emission regulations.


Handling

Auto Fork Leveling System

With the auto tilt button pushed and tilting forward or backwards, the mast will stop in the upright position.


Performance

Speed Limiter

A programmable speed limiter is standard delivered on the truck. The maximum speed can be programmed through the display by a service technician. Not on 25-30-33D-9E series.


Large Engine Hood

Highly accessible engine compartment assures fast and efficient maintenance. The enlarged air cleaner (8”) extended service time of engine.


Maintenance Management Display

Fast and easy access to maintenance information via the display ensures optimised up-time. When service is needed the driver receives a clear warning for quick interventions.


Safety

Hyundai 9-Series Forklifts

Hyundai introduces the 9-series forklifts. The newly designed counterbalance trucks provide optimal safety, optimised ergonomics and offer a benchmark for serviceability.
