20 D-7 Hyundai diesel forklift specs & dimensions (2008 - 2009)

The Hyundai 20 D-7 is a diesel forklift manufactured from 2008 to 2009. It has a weight of 3.604 tons and a nominal load at the ce…

The Hyundai 20 D-7 is a diesel forklift manufactured from 2008 to 2009. It has a weight of 3.604 tons and a nominal load at the center of gravity of 2 tons. The lifting height reaches up to 4.7 meters, with a center of gravity at 500 mm. It has a maximum climbing ability of 40.1 percent. The total width of the forklift is 1160 mm, and it can travel at a speed of 18.9 km/h with or without load. The turning radius is 2.252 meters, and the construction height is 2160 mm.

Diesel Forklifts Hyundai 20 D-7

Visit Hyundai live at

Technical specs - 20 D-7 Hyundai

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Nominal load at COG
2 t
Centre of gravity
500 mm
Standard tyres
L4
Transmission type
W
Weight
3.604 t
Total width
1160 mm
Construction height
2160 mm
Turning radius
2.252 m
Lifting height
4.7 m
Travel speed with / without load
18.9 km/h
Hoisting with / without load
0.45/0.59 m/s
Lowering with load
0.5/0.45 m/s
max. climbing ability
40.1 %
Model series
7
Engine manuf.
Kubota
Engine type
V3300
Engine power
46 kW

More technical details, like: dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

L = pneumatic tyres, x = drive, SE = superelastic, P = PUR (Elastollan, Vulkollan), V = solid rubber, ND = low pressure tyres, 3 = three-wheel, 4 = four-wheel, 6 = six-wheel All specifications and prices refer to basic models with standard fork carrier, 2 standard prongs, without additional hydraulics with Simplex mast (3,3m up to 10t • 5m > 10t load capacity)
