CPCD20T8-C490 EP diesel forklift specs & dimensions (2024 - 2026)

Name: EP CPCD20T8-C490 Diesel Forklifts
Brand: EP

Nominal load at COG: 2t – Centre of gravity: 500mm – Standard tyres: F: 7.00-12-12PR / R: 6.00-9-10PR – Weight: 3.58t – Total widt…

Nominal load at COG: 2t – Centre of gravity: 500mm – Standard tyres: F: 7.00-12-12PR / R: 6.00-9-10PR – Weight: 3.58t – Total width: 1150mm – Construction height: 2130mm

EP is the manufacturer of the CPCD20T8-C490 diesel forklift. The production years for this model are (2024 - 2026). Find here detailed specs for CPCD20T8-C490 diesel powered lift truck - in a form of table chart below and downloadable datasheet. Explore also the other forklift models produced by EP.

CPCD20T8-C490

Years of manufacture: 2024—2026

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - CPCD20T8-C490 EP

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Nominal load at COG: 2 t

Centre of gravity: 500 mm

Standard tyres: F: 7.00-12-12PR / R: 6.00-9-10PR

Weight: 3.58 t

Total width: 1150 mm

Construction height: 2130 mm

Turning radius: 2.17 m

Lifting height: 3 m

Travel speed with / without load: 20 km/h

Hoisting with / without load: 0.45 m/s

Lowering with load: 0.45 m/s

max. climbing ability: 20 %

Model series: CPCD

Engine manuf.: Xinchai

Engine type: C490BPG-25

Engine power: 36.8 kW

Displacement: 2.67 l

Revolutions at max torque: 1900 rpm

Max. torque: 156 Nm

No. of cylinders: 4

Cylinder bore x stroke: 90x105 mm

More technical details, like: transmission type, dimension lxwxh, emission level are available in the full technical specs.

L = pneumatic tyres, x = drive, SE = superelastic, P = PUR (Elastollan, Vulkollan), V = solid rubber, ND = low pressure tyres, 3 = three-wheel, 4 = four-wheel, 6 = six-wheel All specifications and prices refer to basic models with standard fork carrier, 2 standard prongs, without additional hydraulics with Simplex mast (3,3m up to 10t • 5m > 10t load capacity)
