Lectura specs Forklifts Diesel Forklifts Diesel Forklifts Doosan Doosan D80S-7 specifications

Technical specs - D80S-7 Doosan

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Nominal load at COG 8 t
Centre of gravity 600 mm
Total width 2230 mm
Construction height 2771 mm
Turning radius 3.65 m
Travel speed with / without load 30.9/- km/h
Hoisting with / without load 0.42/- m/s
Engine manuf. Doosan
Engine type D34
Engine power 80.9 kW
Displacement 3.409 l
Revolutions at max torque 1600 rpm
Max. torque 375 Nm
No. of cylinders 4
Emission level Stage IV
Standard tyres ###
Transmission type ###
Weight ###
Lifting height ###
Lowering with load ###
max. climbing ability ###
Engine power ###
Dimension lxwxh ###
Cylinder bore x stroke ###
Weight ###

L = pneumatic tyres, x = drive, SE = superelastic, P = PUR (Elastollan, Vulkollan), V = solid rubber, ND = low pressure tyres, 3 = three-wheel, 4 = four-wheel, 6 = six-wheel All specifications and prices refer to basic models with standard fork carrier, 2 standard prongs, without additional hydraulics with Simplex mast (3,3m up to 10t • 5m > 10t load capacity)
