CD35S-7 Crown diesel forklift specs & dimensions (2022 - 2026)

Name: Crown CD35S-7 Diesel Forklifts
Brand: Crown

The Crown CD35S-7 is a diesel forklift manufactured by Crown since 2022. It has a weight of 6.04 tons and a nominal load at the ce…

The Crown CD35S-7 is a diesel forklift manufactured by Crown since 2022. It has a weight of 6.04 tons and a nominal load at the center of gravity of 3.5 tons. The lifting height reaches up to 3 meters, with a center of gravity at 600 mm. It has a maximum climbing ability of 44.7 percent. The hoisting speed with load is 0 m/s, and the lowering speed with load is 0.45 m/s. The total width of the forklift is 1370 mm, and it can travel at a speed of 25 km/h with or without load. The turning radius is 2.782 meters, and the construction height is 2225 mm.

CD35S-7

Years of manufacture: 2022—2026

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - CD35S-7 Crown

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Nominal load at COG: 3.5 t

Centre of gravity: 600 mm

Standard tyres: Pneumatic 2x/2

Weight: 6.04 t

Total width: 1370 mm

Construction height: 2225 mm

Turning radius: 2.782 m

Lifting height: 3 m

Travel speed with / without load: 25.0/27.0 km/h

Hoisting with / without load: 0.56/0.60 m/s

Lowering with load: 0.45 m/s

max. climbing ability: 44.7 %

Model series: CD

Engine manuf.: Doosan

Engine type: D34NAP

Engine power: 55 kW

Displacement: 3.409 l

Revolutions at max torque: 1400 rpm

Max. torque: 330 Nm

No. of cylinders: 4

Emission level: EPA Tier 4

More technical details, like: transmission type, dimension lxwxh, cylinder bore x stroke are available in the full technical specs.

L = pneumatic tyres, x = drive, SE = superelastic, P = PUR (Elastollan, Vulkollan), V = solid rubber, ND = low pressure tyres, 3 = three-wheel, 4 = four-wheel, 6 = six-wheel All specifications and prices refer to basic models with standard fork carrier, 2 standard prongs, without additional hydraulics with Simplex mast (3,3m up to 10t • 5m > 10t load capacity)
