Drago 200 Cesab diesel forklift specs & dimensions (2003 - 2008)

The Cesab Drago 200 is a diesel forklift manufactured by Cesab from 2003 to 2008. It has a weight of 3.4 tons and a nominal load a…

The Cesab Drago 200 is a diesel forklift manufactured by Cesab from 2003 to 2008. It has a weight of 3.4 tons and a nominal load at the center of gravity of 2 tons. The center of gravity is located at 500mm. The forklift has a total width of 1098mm and a construction height of 2120mm.

Diesel Forklifts Cesab Drago 200

Technical specs - Drago 200 Cesab

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Nominal load at COG
2 t
Centre of gravity
500 mm
Standard tyres
SE/L 4
Transmission type
HY
Weight
3.4 t
Total width
1098 mm
Construction height
2120 mm
Model series
Drago
Engine manuf.
Toyota
Engine type
1 DZ-III
Engine power
36 kW

More technical details, like: turning radius, lifting height, travel speed with / without load, hoisting with / without load, lowering with load, max. climbing ability, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

L = pneumatic tyres, x = drive, SE = superelastic, P = PUR (Elastollan, Vulkollan), V = solid rubber, ND = low pressure tyres, 3 = three-wheel, 4 = four-wheel, 6 = six-wheel All specifications and prices refer to basic models with standard fork carrier, 2 standard prongs, without additional hydraulics with Simplex mast (3,3m up to 10t • 5m > 10t load capacity)

Buy & Rent

Used Cesab Diesel Forklifts for sale

LECTURA gathers most relevant deals from many sources about Diesel Forklifts.
Find current offers on often visited classified marketplaces presenting second hand Diesel Forklifts to buy in many countries.

Get in touch for more details:

Used Cesab Diesel Forklifts for sale | Forklift-International
Go to the offers

Compare Cesab Drago 200 with similar Diesel Forklifts

Cesab Drago 200

Cesab Drago 200

Nominal load at COG:
2 t
Centre of gravity:
500 mm
Standard tyres:
SE/L 4
Transmission type:
HY
Yale GDP 16 AF

Yale GDP 16 AF

Nominal load at COG:
1.6 t
Centre of gravity:
500 mm
Standard tyres:
SE 4
Transmission type:
W
Samsung SF 20 D

Samsung SF 20 D

Nominal load at COG:
2 t
Centre of gravity:
500 mm
Standard tyres:
SE2x/2
Transmission type:
W
Halla HDF 20

Halla HDF 20

Nominal load at COG:
2 t
Centre of gravity:
500 mm
Standard tyres:
L 4
Transmission type:
HY/W
Desta DV 16 A

Desta DV 16 A

Nominal load at COG:
1.6 t
Centre of gravity:
500 mm
Standard tyres:
L 4
Transmission type:
W
