Specification & technical data
EKS 5 Light
Monitoring the lifting condition of the crane at all times EKS works together with, but independently of the ECOS as a complete command and control system or separately as a load moment indicator.
Ecos
Electronic Crane Operating System - ECOS enables control of the entire crane's principle operations. Simple programming eases lift planning and a supply of essential information allows full concentration on the lift itself.
Crane Control System
Full electronic control of all crane movements using electrical control levers with automatic reset to zero. Controls are integrated with the LMI and engine management system by CAN-BUS. ECOS system with graphic display.
Hydraulic System
Two separate circuits, one axial piston variable displacement pump (load sensing) with electronic power limiting control and one gear pump for swing. Dual thermostatically controlled oil coolers keep oil at optimum operating temperature. Tank capacity: 840 L (222 gal).
Miscellaneous Standard Equipment
Work light; tool kit; fire extinguisher; auxiliary boom nose; radio/CD player in carrier cab; cruise control; wind speed indicator; and working lights for each outrigger beam. CraneSTAR asset management system.
