Link-Belt ATC-3210 crane - load chart, specs (2017 - 2023)
max. carrying capacity: 182t – at reach: 2.4m – Carrying capacity: 3.2t – at max. reach: 56m – max. standard boom: 61.1m – Min. st... Read more
max. carrying capacity: 182t – at reach: 2.4m – Carrying capacity: 3.2t – at max. reach: 56m – max. standard boom: 61.1m – Min. standard boom: 13.5m
See load chart, specs, capacity, size and other technical data for Link-Belt ATC-3210 crane manufactured between 2017 - 2023. See information, like: max. carrying capacity: 182t – at reach: 2.4m – Carrying capacity: 3.2t – at max. reach: 56m – max. standard boom: 61.1m – Min. standard boom: 13.5m and more.
Technical specs - ATC-3210 Link-Belt
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur.Contact our team with any change suggestion.
- max. carrying capacity 182 t
- at reach 2.4 m
- Carrying capacity 3.2 t
- at max. reach 56 m
- max. standard boom 61.1 m
- Min. standard boom 13.5 m
- Max. luffing jib 20.42 m
- max. hook height 99.6 m
- Undercarriage engine 413 kW
- Superstructure engine 152 kW
- Travel speed 100 km/h
- Number of axles 5
- Wheels/Drive/Steering 10x6
- axle load 12 t
- Standard tyres 525/80R25
- Outriggers spacing length 7.77 m
- Outriggers spacing width 7.77 m
- Model series 1
- Engine manuf. Cummins
- Engine type QSX 15
- Engine power 413 kW
- Displacement 14.945 l
- Revolutions at max torque 1200 rpm
- Max. torque 2508 Nm
- No. of cylinders 6
- Cylinder bore x stroke 136,9x169 mm
- Emission level Tier 3
More technical details, like: load torque, average fuel consumption, fuel consumption range (min - max), tipping load, dimension lxwxh, weight are available in the full technical specs.
Including hook block
Special equipment
- 2nd winch
- max. luffing jib
- max. fold hydr.
- Erection tip
- Foucault current brake
- Add. ballast
