AR 250 e weycor AR 250 e Specifications & Technical Data (2017—2019)

The Weycor AR 250 e is a wheel loader manufactured by Weycor from 2017 to 2019. It has a weight of 13.9 tons and a transport lengt…

The Weycor AR 250 e is a wheel loader manufactured by Weycor from 2017 to 2019. It has a weight of 13.9 tons and a transport length of 7.48 meters. The bucket capacity is 2.4 cubic meters with a width of 1.9 meters. The maximum discharge height is 2.48 meters. It has a travel speed of 20 km/h and a transport width of 2.46 meters. The transport height is 3.26 meters. The lifting force is 11.6 kN and the turning radius outside is 5.497 meters. It is equipped with a diesel particulate filter, quick hitch hydr., and telescopic features.

Wheel Loaders weycor AR 250 e
Wheel Loaders weycor AR 250 e
Wheel Loaders weycor AR 250 e
Wheel Loaders weycor AR 250 e
Wheel Loaders weycor AR 250 e
Wheel Loaders weycor AR 250 e

Visit weycor live at

Technical specs - AR 250 e weycor

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
13.9 t
Standard tyres
20.5-25 EM
Bucket width
1.9 m
Bucket capacity
2.4 m³
Bucket capacity min.
2.4 m³
Steering mode
KL
Transport length
7.48 m
Transport width
2.46 m
Transport height
3.26 m
Travel speed
20 km/h
Max. discharge height
2.48 m
Turning radius outside
5.497 m
Lifting force
11.6 kN
Model series
AR
Engine manuf.
Deutz
Engine type
TCD6.1 L6
Engine power
160 kW
Emission level
EU V

More technical details, like: bucket capacity max., dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke are available in the full technical specs.

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter
Yes
Swing loader
No
telescopic
Yes
Aircondition
No
Quick hitch hydr.
Yes
Quick hitch mech.
No

Download datasheets (PDF)

weycor AR 250 e FAQ

When was the weycor AR 250 e manufactured?

The weycor AR 250 e was manufactured from 2017 to 2019.

How much does the weycor AR 250 e wheel loader weigh?

The weycor AR 250 e wheel loader weighs 13.9 tons.

What are the transport dimensions of the weycor AR 250 e wheel loader?

The weycor AR 250 e has a transport length of 7.48 meters, a transport width of 2.46 meters, and a transport height of 3.26 meters.

What is the travel speed of the weycor AR 250 e wheel loader?

The weycor AR 250 e wheel loader has a travel speed of 20 km/h.

What are the tyre specifications of the weycor AR 250 e wheel loader?

The weycor AR 250 e wheel loader is equipped with standard tyres sized 20.5-25 EM.

What are the maneuverability specifications of the weycor AR 250 e wheel loader?

The weycor AR 250 e has an articulated-frame steering system and an outside turning radius of 5.497 meters.

What is the lifting force of the weycor AR 250 e wheel loader?

The weycor AR 250 e wheel loader has a lifting force of 11.6 kN.

What is the maximum discharge height of the weycor AR 250 e wheel loader?

The weycor AR 250 e wheel loader has a maximum discharge height of 2.48 meters.

What are the bucket specifications of the weycor AR 250 e wheel loader?

The weycor AR 250 e wheel loader has a bucket capacity of 2.4 cubic meters, a minimum bucket capacity of 2.4 cubic meters, and a bucket width of 1.9 meters.

How much is a weycor AR 250 e Wheel loader (2017u20132019) worth?

The residual value of the weycor AR 250 e depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
