4080T Basic Line Weidemann 4080T Basic Line Specifications & Technical Data (2019—2019)

The Weidemann 4080T Basic Line is a wheel loader manufactured by Weidemann in 2019. It has a weight of 6.1 tons and a transport le…

The Weidemann 4080T Basic Line is a wheel loader manufactured by Weidemann in 2019. It has a weight of 6.1 tons and a transport length of 5.929 meters. The maximum discharge height is 4.226 meters and it has a travel speed of 20 km/h. The transport width is 1.742 meters and the transport height is 2.66 meters. The turning radius outside is 4.275 meters. It is equipped with a quick hitch hydr., telescopic.

Wheel Loaders Weidemann 4080T Basic Line

4080T Basic Line

Years of manufacture: 2019—2019

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - 4080T Basic Line Weidemann

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 6.1 t

Standard tyres: 12.5-20 EM ET0

Steering mode: KL

Transport length: 5.929 m

Transport width: 1.742 m

Transport height: 2.66 m

Travel speed: 20 km/h

Max. discharge height: 4.226 m

Turning radius outside: 4.275 m

Model series: T

Engine manuf.: Deutz

Engine type: TCD2.9 L4

Engine power: 55.4 kW

Displacement: 2.9 l

Revolutions at max torque: 2300 rpm

No. of cylinders: 4

Emission level: III B

More technical details, like: bucket width, bucket capacity, bucket capacity min., bucket capacity max., lifting force, dimension lxwxh, max. torque, cylinder bore x stroke are available in the full technical specs.

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter: No
Swing loader: No
telescopic: Yes
Aircondition: No
Quick hitch hydr.: Yes
Quick hitch mech.: No

Download datasheets (PDF)

Weidemann 4080T Basic Line FAQ

When was the Weidemann 4080T Basic Line manufactured?

The Weidemann 4080T Basic Line was produced in 2019, with production starting and ending in that year.

How much does the Weidemann 4080T Basic Line weigh?

The Weidemann 4080T Basic Line weighs 6.1 tons.

What are the transport dimensions of the Weidemann 4080T Basic Line wheel loader?

The Weidemann 4080T Basic Line has a transport length of 5.93 meters, a transport width of 1.74 meters, and a transport height of 2.66 meters.

What is the travel speed of the Weidemann 4080T Basic Line?

The Weidemann 4080T Basic Line has a travel speed of 20 km/h.

What are the standard tyre specifications of the Weidemann 4080T Basic Line?

The Weidemann 4080T Basic Line has standard tyres sized 12.5-20 EM ET0.

What are the maneuverability specifications of the Weidemann 4080T Basic Line?

The Weidemann 4080T Basic Line has an articulated-frame steering system and an outside turning radius of 4.275 meters.

What is the maximum discharge height of the Weidemann 4080T Basic Line?

The Weidemann 4080T Basic Line has a maximum discharge height of 4.23 meters.
