WL25 Wacker Neuson WL25 Specifications & Technical Data (2019—2026)

The Wacker Neuson WL25 is a wheel loader that has been manufactured since 2019. It has a weight of 2.52 tons and a transport lengt…

The Wacker Neuson WL25 is a wheel loader that has been manufactured since 2019. It has a weight of 2.52 tons and a transport length of 3.321 meters. The bucket capacity is 0.3 cubic meters with a bucket width of 1.25 meters. The maximum discharge height is 2.022 meters and it has a travel speed of 20 km/h. The transport width is 1.194 meters and the transport height is 2.27 meters. It has a lifting force of 24.73 kN and a turning radius outside of 2.593 meters. The bucket capacity is a minimum of 0.3 cubic meters. It also features special equipment such as a quick hitch hydr.

Visit Wacker Neuson live at

WL25

Years of manufacture: 2019—2026

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
Events
News

Technical specs - WL25 Wacker Neuson

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 2.52 t

Standard tyres: 10x16.5 EM

Bucket width: 1.25 m

Bucket capacity: 0.3 m³

Bucket capacity min.: 0.3 m³

Steering mode: KL

Transport length: 3.321 m

Transport width: 1.194 m

Transport height: 2.27 m

Travel speed: 20 km/h

Max. discharge height: 2.022 m

Turning radius outside: 2.593 m

Lifting force: 24.73 kN

Model series: WL

Engine manuf.: Perkins

Engine type: 403J-17

Engine power: 18.4 kW

Displacement: 1.496 l

Revolutions at max torque: 1800 rpm

Max. torque: 90.4 Nm

Emission level: V

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter: No
Swing loader: No
telescopic: No
Aircondition: No
Quick hitch hydr.: Yes
Quick hitch mech.: No

Download datasheets (PDF)

Wacker Neuson WL25 FAQ

When was the Wacker Neuson WL25 manufactured?

The Wacker Neuson WL25 was first produced in 2019.

How much does the Wacker Neuson WL25 weigh?

The Wacker Neuson WL25 weighs 2.52 tons.

What are the transport dimensions of the Wacker Neuson WL25 wheel loader?

The Wacker Neuson WL25 has a transport length of 3.32 meters, a transport width of 1.19 meters, and a transport height of 2.27 meters.

What is the travel speed of the Wacker Neuson WL25 wheel loader?

The Wacker Neuson WL25 has a travel speed of 20 km/h.

What are the undercarriage specifications of the Wacker Neuson WL25?

The Wacker Neuson WL25 is equipped with standard tyres sized 10x16.5 EM.

What are the maneuverability specifications of the Wacker Neuson WL25 wheel loader?

The Wacker Neuson WL25 wheel loader has an articulated-frame steering system and an outside turning radius of 2.593 meters.

What is the lifting force of the Wacker Neuson WL25 wheel loader?

The Wacker Neuson WL25 wheel loader has a lifting force of 24.73 kN.

What is the maximum discharge height of the Wacker Neuson WL25?

The Wacker Neuson WL25 has a maximum discharge height of 2.02 meters.

What are the bucket specifications of the Wacker Neuson WL25 wheel loader?

The Wacker Neuson WL25 has a bucket capacity of 0.3 cubic meters, a minimum bucket capacity of 0.3 cubic meters, and a bucket width of 1.25 meters.

How much is a Wacker Neuson WL25 Wheel loader (2019u20132025) worth?

The residual value of the Wacker Neuson WL25 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
