AL 406 Mustang AL 406 Specifications & Technical Data (2008—2020)
-
Model rating
- 9,00 / 10
Technical specs - AL 406 Mustang
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Weight
- 2.79 t
- Standard tyres
- 31x15.50-15 AS
- Bucket width
- 1.3 m
- Bucket capacity
- 0.4 m³
- Bucket capacity min.
- 0.4 m³
- Steering mode
- KL
- Transport length
- 4.224 m
- Transport width
- 1.195 m
- Transport height
- 2.31 m
- Travel speed
- 20 km/h
- Max. discharge height
- 2.215 m
- Turning radius outside
- 1.427 m
- Model series
- AL
- Engine manuf.
- Yanmar
- Engine type
- 4TNV88
- Engine power
- 35 kW
- Emission level
- Tier 3 a
More technical details, like: bucket capacity max., lifting force, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke are available in the full technical specs.
Basic model with ROPS cabin, std. shovel and teeth
Special equipment
- Diesel particulate filter
-
No
- Swing loader
-
No
- telescopic
-
No
- Aircondition
-
No
- Quick hitch hydr.
-
No
- Quick hitch mech.
-
Yes
Download datasheets (PDF)
