WL25 Wacker Neuson WL25 Specifications & Technical Data (2008—2018)

The Wacker Neuson WL25 is a wheel loader manufactured from 2008 to 2018. It has a weight of 2.38 tons and a transport length of 3.…

The Wacker Neuson WL25 is a wheel loader manufactured from 2008 to 2018. It has a weight of 2.38 tons and a transport length of 3.3 meters. The bucket capacity is 0.35 cubic meters with a bucket width of 1.25 meters. The maximum discharge height is 2.047 meters and it has a travel speed of 20 km/h. The transport width is 1.21 meters and it has a lifting force of 24.73 kN. The bucket capacity minimum is 0.35 cubic meters. It is equipped with a quick hitch hydr.

Wheel Loaders Wacker Neuson WL25
Wheel Loaders Wacker Neuson WL25
Wheel Loaders Wacker Neuson WL25
Wheel Loaders Wacker Neuson WL25
Wheel Loaders Wacker Neuson WL25
Wheel Loaders Wacker Neuson WL25
Wheel Loaders Wacker Neuson WL25
Wheel Loaders Wacker Neuson WL25

Visit Wacker Neuson live at

Technical specs - WL25 Wacker Neuson

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
2.38 t
Standard tyres
10x16.5 EM
Bucket width
1.25 m
Bucket capacity
0.35 m³
Bucket capacity min.
0.35 m³
Steering mode
KL
Transport length
3.3 m
Transport width
1.21 m
Travel speed
20 km/h
Max. discharge height
2.047 m
Turning radius outside
1.33 m
Lifting force
24.73 kN
Model series
WL
Engine manuf.
Perkins
Engine type
404D-15
Engine power
55.4 kW
Displacement
2.9 l
Revolutions at max torque
2300 rpm
No. of cylinders
4
Emission level
III B

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter
No
Swing loader
No
telescopic
No
Aircondition
No
Quick hitch hydr.
Yes
Quick hitch mech.
No

Download datasheets (PDF)

Wacker Neuson WL25 FAQ

When was the Wacker Neuson WL25 manufactured?

The Wacker Neuson WL25 was manufactured from 2008 to 2018.

How much does the Wacker Neuson WL25 weigh?

The Wacker Neuson WL25 weighs 2.38 tons.

What are the transport dimensions of the Wacker Neuson WL25?

The Wacker Neuson WL25 has a transport length of 3.3 meters and a transport width of 1.21 meters.

What is the travel speed of the Wacker Neuson WL25 wheel loader?

The Wacker Neuson WL25 has a travel speed of 20 km/h.

What are the undercarriage specifications of the Wacker Neuson WL25?

The Wacker Neuson WL25 is equipped with standard tyres sized 10x16.5 EM.

What are the maneuverability specifications of the Wacker Neuson WL25 wheel loader?

The Wacker Neuson WL25 has an articulated-frame steering system and an outside turning radius of 1.33 meters.

What is the lifting force rating of the Wacker Neuson WL25 wheel loader?

The Wacker Neuson WL25 wheel loader has a lifting force of 24.73 kN.

What is the maximum discharge height of the Wacker Neuson WL25 wheel loader?

The Wacker Neuson WL25 has a maximum discharge height of 2.05 meters.

What are the specifications of the bucket on the Wacker Neuson WL25 wheel loader?

The Wacker Neuson WL25 wheel loader has a bucket capacity of 0.35 cubic meters and a bucket width of 1.25 meters.

How much is a Wacker Neuson WL25 Wheel loader (2008u20132018) worth?

The residual value of the Wacker Neuson WL25 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
