L 15 Sveloader L 15 Specifications & Technical Data (2007—2011)

The Sveloader L 15 is a wheel loader manufactured by Sveloader from 2007 to 2011. It has a weight of 15 tons and a transport lengt…

The Sveloader L 15 is a wheel loader manufactured by Sveloader from 2007 to 2011. It has a weight of 15 tons and a transport length of 7.04 meters. The bucket capacity is 2.6 cubic meters with a width of 2.6 meters. The maximum discharge height is 2.8 meters. It has a travel speed of 40 km/h and a transport width of 2.63 meters. The transport height is 3.27 meters. The lifting force is 1090 kN and the turning radius outside is 5 meters. It is equipped with special features such as air conditioning and a quick hitch mechanism.

L 15

Years of manufacture: 2007—2011

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - L 15 Sveloader

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 15 t

Standard tyres: 20.5x25

Bucket width: 2.6 m

Bucket capacity: 2.6 m³

Bucket capacity min.: 2.6 m³

Steering mode: KL

Transport length: 7.04 m

Transport width: 2.63 m

Transport height: 3.27 m

Travel speed: 40 km/h

Max. discharge height: 2.8 m

Turning radius outside: 5 m

Lifting force: 1090 kN

Engine manuf.: Mercedes-Benz

Engine type: OM904 LAT

Engine power: 130 kW

More technical details, like: bucket capacity max., model series, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter: No
Swing loader: No
telescopic: No
Aircondition: Yes
Quick hitch hydr.: No
Quick hitch mech.: Yes

Download datasheets (PDF)

Sveloader L 15 FAQ

When was the Sveloader L 15 manufactured?

The Sveloader L 15 was manufactured from 2007 to 2011.

How much does the Sveloader L 15 weigh?

The Sveloader L 15 weighs 15 tons.

What are the transport dimensions of the Sveloader L 15 wheel loader?

The Sveloader L 15 has a transport length of 7.04 meters, a transport width of 2.63 meters, and a transport height of 3.27 meters.

What is the travel speed of the Sveloader L 15 wheel loader?

The Sveloader L 15 has a travel speed of 40 km/h.

What are the undercarriage specifications of the Sveloader L 15?

The Sveloader L 15 is equipped with standard tyres sized 20.5x25.

What are the maneuverability specifications of the Sveloader L 15 wheel loader?

The Sveloader L 15 has an outside turning radius of 5 meters and features articulated-frame steering.

What is the power rating of the Sveloader L 15?

The source data does not provide the power rating for the Sveloader L 15.

What is the maximum discharge height of the Sveloader L 15?

The Sveloader L 15 has a maximum discharge height of 2.8 meters.

What are the bucket specifications of the Sveloader L 15 wheel loader?

The Sveloader L 15 has a bucket capacity of 2.6 cubic meters, a minimum bucket capacity of 2.6 cubic meters, and a bucket width of 2.6 meters.
