2436 SLT Schäffer 2436 SLT Specifications & Technical Data (2016—2018)

The Schäffer 2436 SLT is a wheel loader manufactured from 2016 to 2018. It has a weight of 2.45 tons and a transport length of 4.1…

The Schäffer 2436 SLT is a wheel loader manufactured from 2016 to 2018. It has a weight of 2.45 tons and a transport length of 4.11 meters. The bucket capacity is 0.5 cubic meters with a width of 1.3 meters. The maximum discharge height is 1.7 meters. It has a travel speed of 20 km/h and a transport width of 1.02 meters. The transport height is 1.95 meters and the turning radius outside is 2.55 meters. The minimum bucket capacity is also 0.5 cubic meters.

2436 SLT

Years of manufacture: 2016—2018

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - 2436 SLT Schäffer

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 2.45 t

Standard tyres: 10.0/75-15.3 AS

Bucket width: 1.3 m

Bucket capacity: 0.5 m³

Bucket capacity min.: 0.5 m³

Steering mode: KL

Transport length: 4.11 m

Transport width: 1.02 m

Transport height: 1.95 m

Travel speed: 20 km/h

Max. discharge height: 1.7 m

Turning radius outside: 2.55 m

Engine manuf.: Kubota

Engine type: k.A.

Engine power: 26 kW

Revolutions at max torque: 2800 rpm

No. of cylinders: 3

More technical details, like: bucket capacity max., lifting force, model series, dimension lxwxh, displacement, max. torque, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter: No
Swing loader: No
telescopic: No
Aircondition: No
Quick hitch hydr.: No
Quick hitch mech.: No

Download datasheets (PDF)

2436 SLT Schäffer Specification for Europe (DE)

Schäffer 2436 SLT FAQ

When was the Schu00e4ffer 2436 SLT manufactured?

The Schu00e4ffer 2436 SLT was manufactured from 2016 to 2018.

How much does the Schu00e4ffer 2436 SLT wheel loader weigh?

The Schu00e4ffer 2436 SLT wheel loader weighs 2.45 tons.

What are the transport dimensions of the Schu00e4ffer 2436 SLT wheel loader?

The Schu00e4ffer 2436 SLT has a transport length of 4.11 meters, a transport width of 1.02 meters, and a transport height of 1.95 meters.

What is the travel speed of the Schu00e4ffer 2436 SLT wheel loader?

The Schu00e4ffer 2436 SLT has a travel speed of 20 km/h.

What are the undercarriage specifications of the Schu00e4ffer 2436 SLT wheel loader?

The Schu00e4ffer 2436 SLT wheel loader is equipped with standard tyres sized 10.0/75-15.3 AS.

What are the maneuverability specifications of the Schu00e4ffer 2436 SLT wheel loader?

The Schu00e4ffer 2436 SLT has an articulated-frame steering system and an outside turning radius of 2.55 meters.

What is the material handling capacity of the Schu00e4ffer 2436 SLT in terms of discharge height?

The Schu00e4ffer 2436 SLT has a maximum discharge height of 1.7 meters.

What are the specifications of the bucket on the Schu00e4ffer 2436 SLT wheel loader?

The Schu00e4ffer 2436 SLT has a bucket with a capacity of 0.5 cubic meters, a minimum bucket capacity of 0.5 cubic meters, and a bucket width of 1.3 meters.

How much is a Schu00e4ffer 2436 SLT Wheel loader (2016u20132018) worth?

The residual value of the Schu00e4ffer 2436 SLT depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
