2430-2 Schäffer 2430-2 Specifications & Technical Data (2025—2026)

Weight: 2.55t – Standard tyres: 10.0/75-15.3 MPT, ET-40 – Bucket width: 1.3m – Bucket capacity: 0.5m³ – Steering mode: KL – Transport length: 4.23m

2430-2

Years of manufacture: 2025—2026

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - 2430-2 Schäffer

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 2.55 t

Standard tyres: 10.0/75-15.3 MPT, ET-40

Bucket width: 1.3 m

Bucket capacity: 0.5 m³

Steering mode: KL

Transport length: 4.23 m

Transport width: 1.59 m

Transport height: 2.18 m

Travel speed: 20 km/h

Max. discharge height: 1.6 m

Turning radius outside: 3.045 m

Engine manuf.: Kubota

Engine type: D1703-M-DI

Engine power: 18.5 kW

Displacement: 1.647 l

Revolutions at max torque: 2400 rpm

No. of cylinders: 3

Emission level: V

More technical details, like: bucket capacity min., bucket capacity max., lifting force, model series, dimension lxwxh, max. torque, cylinder bore x stroke are available in the full technical specs.

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter: No
Swing loader: No
telescopic: No
Aircondition: No
Quick hitch hydr.: No
Quick hitch mech.: No

Download datasheets (PDF)

2430-2 Schäffer Specification for Europe (DE)

Schäffer 2430-2 FAQ

When was the Schu00e4ffer 2430-2 manufactured?

The Schu00e4ffer 2430-2 was first produced in 2025.

How much does the Schu00e4ffer 2430-2 weigh?

The Schu00e4ffer 2430-2 weighs 2.55 tons.

What are the transport dimensions of the Schu00e4ffer 2430-2 wheel loader?

The Schu00e4ffer 2430-2 has a transport length of 4.23 meters, a transport width of 1.37 meters, and a transport height of 2.18 meters.

What is the travel speed of the Schu00e4ffer 2430-2 wheel loader?

The Schu00e4ffer 2430-2 has a travel speed of 20 km/h.

What are the undercarriage specifications of the Schu00e4ffer 2430-2 wheel loader?

The Schu00e4ffer 2430-2 wheel loader is equipped with standard tyres sized 10.0/75-15.3 MPT, ET-40.

What are the maneuverability specifications of the Schu00e4ffer 2430-2 wheel loader?

The Schu00e4ffer 2430-2 wheel loader has an articulated-frame steering mode and an outside turning radius of 2.54 meters.

What is the maximum discharge height of the Schu00e4ffer 2430-2 wheel loader?

The Schu00e4ffer 2430-2 wheel loader has a maximum discharge height of 1.6 meters.
