TL 210 Schaeff TL 210 Specifications & Technical Data (2017—2017)

The Schaeff TL 210 is a wheel loader manufactured by Schaeff in 2017. It has a weight of 12.5 tons and a transport length of 7.09 …

The Schaeff TL 210 is a wheel loader manufactured by Schaeff in 2017. It has a weight of 12.5 tons and a transport length of 7.09 meters. The bucket width is 2.5 meters and it has a maximum discharge height of 3.01 meters. The travel speed of the wheel loader is 40 km/h. It has a transport width of 2.5 meters and a transport height of 3.26 meters. The lifting force of the machine is 123.4 kN. The turning radius outside is 5.97 meters. The bucket capacity ranges from a maximum of 3.5 cubic meters to a minimum of 2 cubic meters. The special equipment included is a quick hitch mechanism.

TL 210

Years of manufacture: 2017—2017

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - TL 210 Schaeff

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 12.5 t

Standard tyres: 20.5-25

Bucket width: 2.5 m

Bucket capacity min.: 2 m³

Bucket capacity max.: 3.5 m³

Steering mode: KL

Transport length: 7.09 m

Transport width: 2.5 m

Transport height: 3.26 m

Travel speed: 40 km/h

Max. discharge height: 3.01 m

Turning radius outside: 5.97 m

Lifting force: 123.4 kN

Engine manuf.: Cummins

Engine type: QSB6.7

Engine power: 119 kW

Displacement: 6.7 l

Revolutions at max torque: 2200 rpm

No. of cylinders: 6

Emission level: Euro III a/Tier 3

More technical details, like: bucket capacity, model series, dimension lxwxh, max. torque, cylinder bore x stroke are available in the full technical specs.

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter: No
Swing loader: No
telescopic: No
Aircondition: No
Quick hitch hydr.: No
Quick hitch mech.: Yes

Download datasheets (PDF)

TL 210 Schaeff Specification for Europe (EN)

Schaeff TL 210 FAQ

When was the Schaeff TL 210 manufactured?

The Schaeff TL 210 was manufactured in 2017.

How much does the Schaeff TL 210 weigh?

The Schaeff TL 210 weighs 12.5 tons.

What are the transport dimensions of the Schaeff TL 210 wheel loader?

The Schaeff TL 210 has a transport length of 7.09 meters, a transport width of 2.5 meters, and a transport height of 3.26 meters.

What is the travel speed of the Schaeff TL 210 wheel loader?

The Schaeff TL 210 has a travel speed of 40 km/h.

What is the standard tyre size of the Schaeff TL 210 wheel loader?

The Schaeff TL 210 wheel loader has standard tyres sized 20.5-25.

What are the maneuverability specifications of the Schaeff TL 210 wheel loader?

The Schaeff TL 210 has an articulated-frame steering mode and an outside turning radius of 5.97 meters.

What is the power rating of the Schaeff TL 210 wheel loader?

The available data does not provide a power rating for the Schaeff TL 210 wheel loader.

What is the material handling capacity of the Schaeff TL 210 in terms of discharge height?

The Schaeff TL 210 has a maximum discharge height of 3.01 meters.

What are the bucket specifications of the Schaeff TL 210 wheel loader?

The Schaeff TL 210 has a bucket width of 2.5 meters with a capacity ranging from 2 to 3.5 cubic meters.
