PL 185 Palazzani PL 185 Specifications & Technical Data (2015—2021)

The Palazzani PL 185 is a wheel loader manufactured from 2015 to 2021. It has a weight of 8.65 tons and a transport length of 6.24…

The Palazzani PL 185 is a wheel loader manufactured from 2015 to 2021. It has a weight of 8.65 tons and a transport length of 6.24 meters. The bucket capacity is 1.5 cubic meters, with a bucket width of 2.35 meters. The maximum discharge height is 3.68 meters, and it has a travel speed of 40 km/h. The transport width and height are both 2.35 and 2.86 meters, respectively. The turning radius outside is 5.12 meters, and it is equipped with a quick hitch mechanism.

PL 185

Years of manufacture: 2015—2021

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - PL 185 Palazzani

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 8.65 t

Standard tyres: 15.5-25

Bucket width: 2.35 m

Bucket capacity: 1.5 m³

Bucket capacity min.: 1.5 m³

Steering mode: KL

Transport length: 6.24 m

Transport width: 2.35 m

Transport height: 2.86 m

Travel speed: 40 km/h

Max. discharge height: 3.68 m

Turning radius outside: 5.12 m

Model series: PL

Engine manuf.: JCB

Engine type: 444 TA 4F

Engine power: 93 kW

Displacement: 4.4 l

Revolutions at max torque: 2200 rpm

Emission level: Tier 4 f

More technical details, like: bucket capacity max., lifting force, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke are available in the full technical specs.

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter: No
Swing loader: No
telescopic: No
Aircondition: No
Quick hitch hydr.: No
Quick hitch mech.: Yes

Download datasheets (PDF)

Palazzani PL 185 FAQ

When was the Palazzani PL 185 manufactured?

The Palazzani PL 185 was manufactured from 2015 to 2021.

How much does the Palazzani PL 185 wheel loader weigh?

The Palazzani PL 185 wheel loader weighs 8.65 tons.

What are the transport dimensions of the Palazzani PL 185 wheel loader?

The Palazzani PL 185 has a transport length of 6.24 meters, a transport width of 2.35 meters, and a transport height of 2.86 meters.

What is the travel speed of the Palazzani PL 185 wheel loader?

The Palazzani PL 185 has a travel speed of 40 km/h.

What is the standard tyre size of the Palazzani PL 185 wheel loader?

The Palazzani PL 185 wheel loader is equipped with standard tyres sized 15.5-25.

What are the maneuverability specifications of the Palazzani PL 185 wheel loader?

The Palazzani PL 185 features articulated-frame steering and has an outside turning radius of 5.12 meters.

What is the maximum discharge height of the Palazzani PL 185 wheel loader?

The Palazzani PL 185 wheel loader has a maximum discharge height of 3.68 meters.

What are the specifications of the bucket on the Palazzani PL 185 wheel loader?

The Palazzani PL 185 wheel loader has a bucket with a capacity of 1.5 cubic meters, a minimum capacity of 1.5 cubic meters, and a width of 2.35 meters.

How much is a Palazzani PL 185 Wheel loader (2015u20132021) worth?

The residual value of the Palazzani PL 185 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.

Palazzani PL 185 overview

Engine / Powertrain / Drivetrain

Transmission

High-pressure, closed-loop hydrostatic transmission, with automatic adjustment of power, axial pistons pump and engine at variable displacement. Inching pedal control for traction regulation is modulating and integrated in the service brake pedal. Additionally, there is automatic working speed selection, providing 4 forward and backward speeds: 2 working speeds and 2 transfer speeds, all controlled electronically via the joystick.

Hydraulic system

Steering

Servosassisted, with hydoguide and articulated chassis. Total steering angle of 80°. The hydraulic system is “Load Sensing” equipped with valve on the primary pump.
