AT900 Mecalac AT900 Specifications & Technical Data (2021—2026)

The Mecalac AT900 is a wheel loader manufactured since 2021. It has a weight of 6.55 tons and a transport length of 5.85 meters. T…

The Mecalac AT900 is a wheel loader manufactured since 2021. It has a weight of 6.55 tons and a transport length of 5.85 meters. The bucket capacity is 0.9 cubic meters, with a maximum discharge height of 4.08 meters. The travel speed is 20 km/h, and the transport width is 2.1 meters. The transport height is 2.91 meters. It has a lifting force of 44 kN and a turning radius outside of 4.6 meters. The bucket capacity ranges from 0.9 to 1.5 cubic meters. It is equipped with a quick hitch hydr.

AT900

Years of manufacture: 2021—2026

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - AT900 Mecalac

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 6.55 t

Standard tyres: 16/70-20

Bucket capacity: 0.9 m³

Bucket capacity min.: 0.9 m³

Bucket capacity max.: 1.5 m³

Steering mode: AL

Transport length: 5.85 m

Transport width: 2.1 m

Transport height: 2.91 m

Travel speed: 20 km/h

Max. discharge height: 4.08 m

Turning radius outside: 4.6 m

Lifting force: 44 kN

Model series: AT

Engine manuf.: Deutz

Engine type: TCD2.9 L4

Engine power: 55.4 kW

Displacement: 2.9 l

Revolutions at max torque: 2300 rpm

Max. torque: 300/1600 Nm

No. of cylinders: 4

Cylinder bore x stroke: 92x110 mm

Emission level: EU V

More technical details, like: bucket width, dimension lxwxh are available in the full technical specs.

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter: No
Swing loader: No
telescopic: No
Aircondition: No
Quick hitch hydr.: Yes
Quick hitch mech.: No

Download datasheets (PDF)

Mecalac AT900 FAQ

When was the Mecalac AT900 manufactured?

The Mecalac AT900 was first produced in 2021.

How much does the Mecalac AT900 wheel loader weigh?

The Mecalac AT900 wheel loader weighs 6.55 tons.

What are the transport dimensions of the Mecalac AT900 wheel loader?

The Mecalac AT900 has a transport length of 5.85 meters, a transport width of 2.1 meters, and a transport height of 2.91 meters.

What is the travel speed of the Mecalac AT900 wheel loader?

The Mecalac AT900 has a travel speed of 20 km/h.

What are the undercarriage specifications of the Mecalac AT900?

The Mecalac AT900 is equipped with standard tyres sized 16/70-20.

What are the maneuverability specifications of the Mecalac AT900 wheel loader?

The Mecalac AT900 features all-wheel steering and has an outside turning radius of 4.6 meters.

What is the lifting force of the Mecalac AT900?

The Mecalac AT900 has a lifting force of 44 kN.

What is the maximum discharge height of the Mecalac AT900 wheel loader?

The Mecalac AT900 wheel loader has a maximum discharge height of 4.08 meters.

What are the bucket capacity specifications of the Mecalac AT900 wheel loader?

The Mecalac AT900 wheel loader has a bucket capacity ranging from 0.9 cubic meters to a maximum of 1.5 cubic meters, with a standard bucket capacity of 0.9 cubic meters.
