AT900 Mecalac AT900 Specifications & Technical Data (2017—2020)

The Mecalac AT900 is a wheel loader manufactured from 2017 to 2020. It has a weight of 6.55 tons and a transport length of 5.85 me…

The Mecalac AT900 is a wheel loader manufactured from 2017 to 2020. It has a weight of 6.55 tons and a transport length of 5.85 meters. The bucket capacity is 0.9 cubic meters, and it has a maximum discharge height of 4.08 meters. The travel speed of the machine is 20 km/h. It has a transport width of 2.1 meters and a transport height of 2.91 meters. The lifting force of the wheel loader is 44 kN, and it has a turning radius outside of 4.6 meters. The bucket capacity is a minimum of 0.9 cubic meters. The special equipment of the machine includes a quick hitch hydr.

AT900

Years of manufacture: 2017—2020

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - AT900 Mecalac

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 6.55 t

Standard tyres: 16/70-20

Bucket capacity: 0.9 m³

Bucket capacity min.: 0.9 m³

Steering mode: AL

Transport length: 5.85 m

Transport width: 2.1 m

Transport height: 2.91 m

Travel speed: 20 km/h

Max. discharge height: 4.08 m

Turning radius outside: 4.6 m

Lifting force: 44 kN

Model series: AT

Engine manuf.: Deutz

Engine type: TCD2.9 L4

Engine power: 55.4 kW

Revolutions at max torque: 2600 rpm

Max. torque: 300/1600 Nm

No. of cylinders: 4

Emission level: Tier 4 f

More technical details, like: bucket width, bucket capacity max., dimension lxwxh, displacement, cylinder bore x stroke are available in the full technical specs.

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter: No
Swing loader: No
telescopic: No
Aircondition: No
Quick hitch hydr.: Yes
Quick hitch mech.: No

Download datasheets (PDF)

Mecalac AT900 FAQ

When was the Mecalac AT900 manufactured?

The Mecalac AT900 was manufactured from 2017 to 2020.

How much does the Mecalac AT900 wheel loader weigh?

The Mecalac AT900 wheel loader weighs 6.55 tons.

What are the transport dimensions of the Mecalac AT900 wheel loader?

The Mecalac AT900 has a transport length of 5.85 meters, a transport width of 2.1 meters, and a transport height of 2.91 meters.

What is the travel speed of the Mecalac AT900 wheel loader?

The Mecalac AT900 has a travel speed of 20 km/h.

What are the undercarriage specifications of the Mecalac AT900 wheel loader?

The Mecalac AT900 wheel loader is equipped with standard tyres sized 16/70-20.

What are the maneuverability specifications of the Mecalac AT900 wheel loader?

The Mecalac AT900 has an outside turning radius of 4.6 meters and features all-wheel steering.

What is the lifting force of the Mecalac AT900 wheel loader?

The Mecalac AT900 wheel loader has a lifting force of 44 kN.

What is the material handling capacity in terms of discharge height of the Mecalac AT900?

The Mecalac AT900 has a maximum discharge height of 4.08 meters for material handling.

What is the bucket capacity of the Mecalac AT900 wheel loader?

The Mecalac AT900 wheel loader has a bucket capacity of 0.9 cubic meters.

How much is a Mecalac AT900 Wheel loader (2017u20132020) worth?

The residual value of the Mecalac AT900 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
