AS900tele Mecalac AS900tele Specifications & Technical Data (2015—2020)

The Mecalac AS900tele is a wheel loader manufactured by Mecalac from 2015 to 2020. It has a weight of 7.25 tons and a transport le…

The Mecalac AS900tele is a wheel loader manufactured by Mecalac from 2015 to 2020. It has a weight of 7.25 tons and a transport length of 6.27 meters. The bucket capacity is 0.7 cubic meters, with a maximum discharge height of 4.1 meters. It has a travel speed of 30 km/h and a transport width of 2.1 meters. The transport height is 2.91 meters. The lifting force of this machine is 37 kN. It has a special equipment feature of a quick hitch hydr., swing loader, and telescopic capabilities. The bucket capacity ranges from a minimum of 0.7 cubic meters to a maximum of 1.2 cubic meters.

AS900tele

Years of manufacture: 2015—2020

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - AS900tele Mecalac

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 7.25 t

Standard tyres: 16/70-20

Bucket capacity: 0.7 m³

Bucket capacity min.: 0.7 m³

Bucket capacity max.: 1.2 m³

Steering mode: AL

Transport length: 6.27 m

Transport width: 2.1 m

Transport height: 2.91 m

Travel speed: 30 km/h

Max. discharge height: 4.1 m

Lifting force: 37 kN

Model series: AS

Engine manuf.: Deutz

Engine type: TCD2.9 L4

Engine power: 55.4 kW

Revolutions at max torque: 2600 rpm

Max. torque: 300/1600 Nm

No. of cylinders: 4

Emission level: Tier 4 f

More technical details, like: bucket width, turning radius outside, dimension lxwxh, displacement, cylinder bore x stroke are available in the full technical specs.

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter: No
Swing loader: Yes
telescopic: Yes
Aircondition: No
Quick hitch hydr.: Yes
Quick hitch mech.: No

Download datasheets (PDF)

Mecalac AS900tele FAQ

When was the Mecalac AS900tele manufactured?

The Mecalac AS900tele was manufactured from 2015 to 2020.

How much does the Mecalac AS900tele weigh?

The Mecalac AS900tele weighs 7.25 tons.

What are the transport dimensions of the Mecalac AS900tele wheel loader?

The Mecalac AS900tele has a transport length of 6.27 meters, a transport width of 2.1 meters, and a transport height of 2.91 meters.

What is the travel speed of the Mecalac AS900tele wheel loader?

The Mecalac AS900tele has a travel speed of 30 km/h.

What is the standard tyre size of the Mecalac AS900tele wheel loader?

The Mecalac AS900tele wheel loader is equipped with standard tyres sized 16/70-20.

What is the steering mode of the Mecalac AS900tele?

The Mecalac AS900tele has an all-wheel steering mode.

What is the lifting force of the Mecalac AS900tele wheel loader?

The Mecalac AS900tele wheel loader has a lifting force of 37 kN.

What is the material handling capacity of the Mecalac AS900tele in terms of discharge height?

The Mecalac AS900tele has a maximum discharge height of 4.1 meters.

What are the bucket capacity specifications of the Mecalac AS900tele wheel loader?

The Mecalac AS900tele has a bucket capacity ranging from a minimum of 0.7 mu00b3 to a maximum of 1.2 mu00b3, with a standard bucket capacity of 0.7 mu00b3.
