AS 150 e Mecalac AS 150 e Specifications & Technical Data (2012—2014)

The Mecalac AS 150 e is a wheel loader manufactured by Mecalac from 2012 to 2014. It has a weight of 11 tons and a transport lengt…

The Mecalac AS 150 e is a wheel loader manufactured by Mecalac from 2012 to 2014. It has a weight of 11 tons and a transport length of 6.58 meters. The bucket capacity is 1.5 cubic meters with a width of 2.48 meters. The maximum discharge height is 3.39 meters. It has a travel speed of 20 km/h and a transport width of 2.46 meters. The transport height is 3.1 meters. The lifting force is 69 kN. It is equipped with special features such as a quick hitch hydr. and a swing loader.

Wheel Loaders Mecalac AS 150 e
Wheel Loaders Mecalac AS 150 e
Wheel Loaders Mecalac AS 150 e
Wheel Loaders Mecalac AS 150 e
Wheel Loaders Mecalac AS 150 e
Wheel Loaders Mecalac AS 150 e
Wheel Loaders Mecalac AS 150 e
Wheel Loaders Mecalac AS 150 e
Wheel Loaders Mecalac AS 150 e
Wheel Loaders Mecalac AS 150 e
Wheel Loaders Mecalac AS 150 e
Wheel Loaders Mecalac AS 150 e
Wheel Loaders Mecalac AS 150 e
Wheel Loaders Mecalac AS 150 e

Technical specs - AS 150 e Mecalac

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
11 t
Standard tyres
17.5-25
Bucket width
2.48 m
Bucket capacity
1.5 m³
Bucket capacity min.
1.5 m³
Steering mode
AL
Transport length
6.58 m
Transport width
2.46 m
Transport height
3.1 m
Travel speed
20 km/h
Max. discharge height
3.39 m
Lifting force
69 kN
Model series
AS
Engine manuf.
Deutz
Engine type
TCD2012 L04 2V
Engine power
100 kW
Revolutions at max torque
1500 rpm

More technical details, like: bucket capacity max., turning radius outside, dimension lxwxh, displacement, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter
No
Swing loader
Yes
telescopic
No
Aircondition
No
Quick hitch hydr.
Yes
Quick hitch mech.
No

Download datasheets (PDF)

Mecalac AS 150 e FAQ

When was the Mecalac AS 150 e manufactured?

The Mecalac AS 150 e was manufactured from 2012 to 2014.

How much does the Mecalac AS 150 e weigh?

The Mecalac AS 150 e weighs 11 tons.

What are the transport dimensions of the Mecalac AS 150 e wheel loader?

The Mecalac AS 150 e has a transport length of 6.58 meters, a transport width of 2.46 meters, and a transport height of 3.1 meters.

What is the travel speed of the Mecalac AS 150 e wheel loader?

The Mecalac AS 150 e has a travel speed of 20 km/h.

What are the undercarriage specifications of the Mecalac AS 150 e wheel loader?

The Mecalac AS 150 e wheel loader is equipped with standard tyres sized 17.5-25.

What is the steering mode of the Mecalac AS 150 e wheel loader?

The Mecalac AS 150 e has all-wheel steering.

What is the lifting force of the Mecalac AS 150 e?

The Mecalac AS 150 e has a lifting force of 69 kN.

What is the maximum discharge height of the Mecalac AS 150 e?

The Mecalac AS 150 e has a maximum discharge height of 3.39 meters.

What are the bucket specifications of the Mecalac AS 150 e wheel loader?

The Mecalac AS 150 e has a bucket capacity of 1.5 cubic meters, a minimum bucket capacity of 1.5 cubic meters, and a bucket width of 2.48 meters.

How much is a Mecalac AS 150 e Wheel loader (2012u20132014) worth?

The residual value of the Mecalac AS 150 e depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.

Mecalac AS 150 e overview

Mecalac AS 150 e features overview

Mecalac Swing Loaders

Multiple operations, easy to maintain and long-lasting components guarantee high profitability and are the brand character of Mecalac swing loaders: Many operations are possible without stabilisers even in confined spaces such as pallet lifting, excavating and materials handling. Extensive range of attachments for almost every application. Western European technical components. Optimal access to all service points. Long maintenance intervals and low maintenance costs. The chain operated swing function has no maintenance or wear for the life of the machine. Free-play is taken up automatically.


Engine / Powertrain / Drivetrain

Let's have a look

Self-engaging, automatic differential lock in front axle (locking factor 45%). Low-maintenance, play-free chain operated swing system with constant turning speed and power. Hydraulically operated quick coupler. Powerful Double-Z-Kinematics with precise parallel lifting and final position cushioning of the lift cylinders.


At your advantages

Safe and easy access on both sides. Spacious and comfortable cab with excellent all-round visibility. Easy handling; nearly all operating functions are integrated in one joystick. High performance Deutz turbo diesel engine. Hydrostatic four-wheel steering. Payload dependent axle support. Low-maintenance wet lamella brakes. Rigid single-component chassis for maximum stability.


Bucket and Ground Engaging Tools

Mecalac Swing Loaders

Mecalac swing loaders are compact, flexible, comfortable, secure and extremely efficient. We have always been at the forefront of innovative design and lead the market in swing shovel technology. They offer short, fast operating cycles for time-saving, excellent manoeuvrability particularly in confined areas, working in one track and shorter travel distance for minimal traffic obstruction, and reduced soil compaction due to fewer operating cycles.
