411 HT JCB 411 HT Specifications & Technical Data (2021—2026)

The JCB 411 HT is a wheel loader manufactured by JCB since 2021. It has a weight of 8.93 tons and a transport length of 6.23 meter…

The JCB 411 HT is a wheel loader manufactured by JCB since 2021. It has a weight of 8.93 tons and a transport length of 6.23 meters. The bucket capacity is 1.2 cubic meters with a width of 2.25 meters. The maximum discharge height is 2.78 meters. It has a travel speed of 40 km/h and a transport width of 2.2 meters. The transport height is 3.06 meters. The lifting force is 73.2 kN and the turning radius outside is 5.35 meters. It is equipped with air conditioning, a diesel particulate filter, and a quick hitch hydraulic system.

Wheel Loaders JCB 411 HT
Wheel Loaders JCB 411 HT
Wheel Loaders JCB 411 HT
Wheel Loaders JCB 411 HT
Wheel Loaders JCB 411 HT
Wheel Loaders JCB 411 HT
Wheel Loaders JCB 411 HT
Wheel Loaders JCB 411 HT
Wheel Loaders JCB 411 HT
Wheel Loaders JCB 411 HT

Visit JCB live at

Technical specs - 411 HT JCB

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
8.93 t
Standard tyres
15.5 R25 XHA
Bucket width
2.25 m
Bucket capacity
1.2 m³
Bucket capacity min.
1.2 m³
Steering mode
KL
Transport length
6.23 m
Transport width
2.2 m
Transport height
3.06 m
Travel speed
40 km/h
Max. discharge height
2.78 m
Turning radius outside
5.35 m
Lifting force
73.2 kN
Engine manuf.
JCB
Engine type
EcoMax
Engine power
81 kW
Displacement
4.8 l
Revolutions at max torque
1450 rpm
Max. torque
516 Nm
No. of cylinders
4
Cylinder bore x stroke
106x139 mm
Emission level
V

More technical details, like: bucket capacity max., model series, dimension lxwxh are available in the full technical specs.

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter
Yes
Swing loader
No
telescopic
No
Aircondition
Yes
Quick hitch hydr.
Yes
Quick hitch mech.
No

JCB 411 HT FAQ

When was the JCB 411 HT manufactured?

The JCB 411 HT was first produced in 2021.

How much does the JCB 411 HT wheel loader weigh?

The JCB 411 HT wheel loader weighs 8.93 tons.

What are the transport dimensions of the JCB 411 HT wheel loader?

The JCB 411 HT has a transport length of 6.23 meters, a transport width of 2.2 meters, and a transport height of 3.06 meters.

What is the travel speed of the JCB 411 HT wheel loader?

The JCB 411 HT wheel loader has a travel speed of 40 km/h.

What are the undercarriage tyre specifications of the JCB 411 HT wheel loader?

The JCB 411 HT wheel loader is equipped with standard tyres sized 15.5 R25 XHA.

What are the maneuverability specifications of the JCB 411 HT wheel loader?

The JCB 411 HT wheel loader has an outside turning radius of 5.35 meters and features articulated-frame steering.

What is the lifting force of the JCB 411 HT wheel loader?

The JCB 411 HT wheel loader has a lifting force of 73.2 kN.

What is the maximum discharge height of the JCB 411 HT?

The JCB 411 HT has a maximum discharge height of 2.78 meters.

What are the specifications of the primary work tool bucket on the JCB 411 HT?

The JCB 411 HT has a bucket with a capacity of 1.2 cubic meters, a minimum bucket capacity of 1.2 cubic meters, and a bucket width of 2.25 meters.
