G2500HD Giant G2500HD Specifications & Technical Data (2020—2026)

The Giant G2500HD is a wheel loader manufactured by Giant since 2020. It has a weight of 2.4 tons and a transport length of 3.247 …

The Giant G2500HD is a wheel loader manufactured by Giant since 2020. It has a weight of 2.4 tons and a transport length of 3.247 meters. The bucket width is 1.4 meters, and it has a maximum discharge height of 2.114 meters. The travel speed of the wheel loader is 10 km/h, and the transport width is 1.08 meters. The transport height is 2.345 meters. It has a lifting force of 24 kN and a turning radius outside of 2.56 meters. The bucket capacity ranges from a maximum of 0.41 cubic meters to a minimum of 0.287 cubic meters. The special equipment included is a quick hitch hydr.

G2500HD

Years of manufacture: 2020—2026

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - G2500HD Giant

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 2.4 t

Standard tyres: 11.5/80-15.3AS

Bucket width: 1.4 m

Bucket capacity min.: 0.287 m³

Bucket capacity max.: 0.41 m³

Steering mode: KL

Transport length: 3.247 m

Transport width: 1.08 m

Transport height: 2.345 m

Travel speed: 10 km/h

Max. discharge height: 2.114 m

Turning radius outside: 2.56 m

Lifting force: 24 kN

Model series: G

Engine manuf.: Kubota

Engine type: D1505

Engine power: 19 kW

No. of cylinders: 4

Emission level: V

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter: No
Swing loader: No
telescopic: No
Aircondition: No
Quick hitch hydr.: Yes
Quick hitch mech.: No

Download datasheets (PDF)

Giant G2500HD FAQ

When was the Giant G2500HD manufactured?

The Giant G2500HD was first produced in 2020.

How much does the Giant G2500HD wheel loader weigh?

The Giant G2500HD wheel loader weighs 2.4 tons.

What are the transport dimensions of the Giant G2500HD wheel loader?

The Giant G2500HD has a transport length of 3.25 meters, a transport width of 1.08 meters, and a transport height of 2.35 meters.

What is the travel speed of the Giant G2500HD wheel loader?

The Giant G2500HD has a travel speed of 10 km/h.

What are the standard tyres specifications of the Giant G2500HD wheel loader?

The Giant G2500HD wheel loader has standard tyres sized 11.5/80-15.3AS.

What are the maneuverability specifications of the Giant G2500HD wheel loader?

The Giant G2500HD has an articulated-frame steering system and an outside turning radius of 2.56 meters.

What is the power rating of the Giant G2500HD wheel loader?

The power rating of the Giant G2500HD wheel loader is not provided in the available data.

What is the maximum discharge height of the Giant G2500HD?

The Giant G2500HD has a maximum discharge height of 2.11 meters.

What are the specifications of the bucket on the Giant G2500HD wheel loader?

The Giant G2500HD wheel loader has a bucket with a maximum capacity of 0.41 cubic meters, a minimum capacity of 0.29 cubic meters, and a width of 1.4 meters.
