DL250-7 Doosan DL250-7 Specifications & Technical Data (2021—2023)

The Doosan DL250-7 is a wheel loader manufactured since 2021. It has a weight of 13.938 tons and a transport length of 7.575 meter…

The Doosan DL250-7 is a wheel loader manufactured since 2021. It has a weight of 13.938 tons and a transport length of 7.575 meters. The bucket capacity is 2.7 cubic meters, with a bucket width of 2.74 meters. The maximum discharge height is 2.696 meters. It has a travel speed of 40 km/h and a transport width of 2.539 meters. The transport height is 3.313 meters. The lifting force is 99 kN, and the turning radius outside is 6.161 meters. The bucket capacity ranges from 2.4 to 2.7 cubic meters. It is equipped with a diesel particulate filter.

Wheel Loaders Doosan DL250-7
Wheel Loaders Doosan DL250-7
Wheel Loaders Doosan DL250-7
Wheel Loaders Doosan DL250-7
Wheel Loaders Doosan DL250-7
Wheel Loaders Doosan DL250-7
Wheel Loaders Doosan DL250-7
Wheel Loaders Doosan DL250-7

Technical specs - DL250-7 Doosan

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
13.94 t
Standard tyres
20.5 R25
Bucket width
2.74 m
Bucket capacity
2.7 m³
Bucket capacity min.
2.4 m³
Bucket capacity max.
2.7 m³
Steering mode
KL
Transport length
7.58 m
Transport width
2.54 m
Transport height
3.31 m
Travel speed
40 km/h
Max. discharge height
2.7 m
Turning radius outside
6.161 m
Lifting force
99 kN
Model series
DL
Engine manuf.
Doosan
Engine type
DL06
Engine power
128 kW
Displacement
5.9 l
Revolutions at max torque
2100 rpm
Max. torque
804/1400 Nm
No. of cylinders
6
Cylinder bore x stroke
100x125 mm
Emission level
V

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter
Yes
Swing loader
No
telescopic
No
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Doosan DL250-7 FAQ

When was the Doosan DL250-7 manufactured?

The Doosan DL250-7 was manufactured from 2021 to 2023.

How much does the Doosan DL250-7 wheel loader weigh?

The Doosan DL250-7 wheel loader weighs 13.94 tons.

What are the transport dimensions of the Doosan DL250-7 wheel loader?

The Doosan DL250-7 has transport dimensions of 7.58 meters in length, 2.54 meters in width, and 3.31 meters in height.

What is the travel speed of the Doosan DL250-7 wheel loader?

The Doosan DL250-7 has a travel speed of 40 km/h.

What is the standard tyre size of the Doosan DL250-7 wheel loader?

The Doosan DL250-7 wheel loader has standard tyres sized 20.5 R25.

What are the maneuverability specifications of the Doosan DL250-7 wheel loader?

The Doosan DL250-7 wheel loader has an articulated-frame steering system and an outside turning radius of 6.161 meters.

What is the power rating of the Doosan DL250-7 wheel loader?

The source data does not provide power rating information for the Doosan DL250-7 wheel loader.

What is the maximum discharge height of the Doosan DL250-7 wheel loader?

The Doosan DL250-7 wheel loader has a maximum discharge height of 2.7 meters.

What are the bucket specifications of the Doosan DL250-7 wheel loader?

The Doosan DL250-7 wheel loader has a bucket capacity ranging from 2.4 to 2.7 cubic meters, with a bucket width of 2.74 meters.

How much is a Doosan DL250-7 Wheel loader (2021u20132023) worth?

The residual value of the Doosan DL250-7 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
