AS 700 Ahlmann AS 700 Specifications & Technical Data (2010—2012)

The Ahlmann AS 700 is a wheel loader manufactured by Ahlmann from 2010 to 2012. It has a weight of 6 tons and a transport length o…

The Ahlmann AS 700 is a wheel loader manufactured by Ahlmann from 2010 to 2012. It has a weight of 6 tons and a transport length of 5.55 meters. The bucket capacity is 0.7 cubic meters, with a maximum discharge height of 3.12 meters. The travel speed of the machine is 20 km/h. It has a transport width of 1.95 meters and a transport height of 2.68 meters. The bucket capacity ranges from a minimum of 0.7 cubic meters to a maximum of 1.2 cubic meters. The AS 700 is equipped with special features such as a quick hitch hydr. and a swing loader.

AS 700

Years of manufacture: 2010—2012

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - AS 700 Ahlmann

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 6 t

Standard tyres: 14.5-20

Bucket capacity: 0.7 m³

Bucket capacity min.: 0.7 m³

Bucket capacity max.: 1.2 m³

Steering mode: AL

Transport length: 5.55 m

Transport width: 1.95 m

Transport height: 2.68 m

Travel speed: 20 km/h

Max. discharge height: 3.12 m

Model series: AS

Engine manuf.: Cummins

Engine type: B3.3

Engine power: 48 kW

Displacement: 3.3 l

Revolutions at max torque: 1600 rpm

More technical details, like: bucket width, turning radius outside, lifting force, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter: No
Swing loader: Yes
telescopic: No
Aircondition: No
Quick hitch hydr.: Yes
Quick hitch mech.: No

Download datasheets (PDF)

Ahlmann AS 700 FAQ

When was the Ahlmann AS 700 manufactured?

The Ahlmann AS 700 was manufactured from 2010 to 2012.

How much does the Ahlmann AS 700 weigh?

The Ahlmann AS 700 weighs 6 tons.

What are the transport dimensions of the Ahlmann AS 700?

The Ahlmann AS 700 has a transport length of 5.55 meters, a transport width of 1.95 meters, and a transport height of 2.68 meters.

What is the travel speed of the Ahlmann AS 700 wheel loader?

The Ahlmann AS 700 has a travel speed of 20 km/h.

What is the standard tyre size of the Ahlmann AS 700 wheel loader?

The Ahlmann AS 700 wheel loader is equipped with standard tyres sized 14.5-20.

What is the steering mode of the Ahlmann AS 700?

The Ahlmann AS 700 has all-wheel steering.

What is the maximum discharge height of the Ahlmann AS 700?

The Ahlmann AS 700 has a maximum discharge height of 3.12 meters.

What are the bucket capacity specifications of the Ahlmann AS 700 wheel loader?

The Ahlmann AS 700 wheel loader has a bucket capacity ranging from a minimum of 0.7 mu00b3 to a maximum of 1.2 mu00b3, with a standard bucket capacity of 0.7 mu00b3.
